Cutler-Hammer KW3400F产品详情
Cutler-Hammer KW3400F是一款用于工业配电系统的塑壳断路器（Molded Case Circuit Breaker,MCCB）。Cutler-Hammer是Eaton（伊顿）旗下的品牌，该系列断路器主要用于保护电气设备和线路免受过载和短路的影响。
以下是该断路器的主要特点和技术规格：
产品类型：塑壳断路器(MCCB)
型号系列：KW系列
核心功能：
过载保护：当电流超过设定值时，断路器内部的热磁脱扣器会启动，在一定延时后自动断开电路。
短路保护：当发生短路故障时，电磁脱扣器会立即动作，迅速切断电路，以防止设备损坏或火灾。
高分断能力：具备高短路分断能力，能够在发生大电流故障时安全可靠地切断电流。
技术规格：
框架电流：400 A。这个数值代表了该断路器所能承受的最大额定电流。
脱扣单元：通常使用热磁脱扣或电子脱扣单元，可根据具体应用进行调整。
极数：通常为三极或四极。
应用领域：
工业配电：在工厂、商业建筑和数据中心的低压配电系统中，作为主开关、分支回路保护或电机保护。
设备保护：用于保护变压器、电容器、发电机等关键设备。
Cutler-Hammer KW3400F Product Details
The Cutler-Hammer KW3400F is a molded case circuit breaker(MCCB)for industrial power distribution systems.Cutler-Hammer is an Eaton brand.This series of circuit breakers is primarily used to protect electrical equipment and lines from overloads and short circuits.
The following are the main features and technical specifications of this circuit breaker:
Product Type:Molded Case Circuit Breaker(MCCB)
Model Series:KW Series
Core Functions:
Overload Protection:When the current exceeds the set value,the thermal-magnetic release within the circuit breaker activates,automatically disconnecting the circuit after a specified delay.
Short-Circuit Protection:When a short-circuit fault occurs,the electromagnetic release immediately operates,rapidly disconnecting the circuit to prevent equipment damage or fire.
High Breaking Capacity:With high short-circuit breaking capacity,it can safely and reliably interrupt current even in high-current faults.
Technical Specifications:
Frame Current:400 A.This value represents the maximum rated current the circuit breaker can handle.
Trip Unit:Typically uses a thermal-magnetic or electronic trip unit,adjustable depending on the specific application.
Number of Poles:Typically three or four poles.
Applications:
Industrial Power Distribution:Used as a main switch,branch circuit protector,or motor protection in low-voltage power distribution systems in factories,commercial buildings,and data centers.
Equipment Protection:Used to protect critical equipment such as transformers,capacitors,and generators.
