ABB CI502-PNIO是一款用于AC500 PLC的通信模块，以下是其产品详情：
基本信息
品牌：ABB
型号：CI502-PNIO
产品类型：PROFINET总线模块
电源电压：24V DC
尺寸：120mm x 27mm x 265mm
重量：约0.2kg
技术参数
通信协议：PROFINET
数据传输速率：100Mbit/s（全双工）
输入输出：8个24VDC数字输入，8个24VDC、最大0.5A的数字晶体管输出，8个可配置的24VDC、最大0.5A的数字输入/输出
总线连接：2个RJ45接口（PNIO 1和PNIO 2），集成2端口交换机
工作温度范围：-40°C至+85°C
防护等级：IP20
功能特点
协议支持：支持PROFINET协议，可实现高效的数据传输和实时控制。
可扩展性强：可扩展多达10个I/O模块以及远程站点，满足不同规模的自动化需求。
安装便捷：支持标准的导轨安装方式，方便用户将其集成到现有的控制系统中。
状态显示：配备5个LED指示灯，用于显示模块的工作状态，便于用户进行故障排查和维护。
高可靠性：采用高质量材料制造，能在恶劣的工业环境下稳定运行。
The ABB CI502-PNIO is a communication module for AC500 PLCs.Product details are as follows:
Basic Information
Brand:ABB
Model:CI502-PNIO
Product Type:PROFINET Bus Module
Power Supply Voltage:24V DC
Dimensions:120mm x 27mm x 265mm
Weight:Approximately 0.2kg
Technical Parameters
Communication Protocol:PROFINET
Data Transfer Rate:100Mbit/s(Full Duplex)
Inputs/Outputs:8 24VDC digital inputs,8 24VDC digital transistor outputs,0.5A maximum,0.5A maximum,8 configurable 24VDC digital inputs/outputs
Bus Connection:2 RJ45 ports(PNIO 1 and PNIO 2),integrated 2-port switch
Operating Temperature Range:-40°C to+85°C
Protection Rating:IP20
Features
Protocol Support:Supports PROFINET Protocol enables efficient data transmission and real-time control.
Strong Scalability:Up to 10 I/O modules and remote sites can be added to meet automation needs of varying scales.
Easy Installation:Supports standard DIN-rail mounting,making it easy to integrate into existing control systems.
Status Display:Equipped with five LED indicators to display the module’s operating status,facilitating troubleshooting and maintenance.
High Reliability:Manufactured from high-quality materials,it operates stably in harsh industrial environments.
