ALSTOM MCHNM01H1AB0500A 130169520115002

1.硬件架构与功能模块

核心处理器:

嵌入式实时操作系统,支持多线程数据处理

支持32位浮点运算,计算精度达±0.05%

输入输出配置:

模拟量输入:8路0-10V/4-20mA输入,支持CT/PT信号适配

数字量I/O:16路DI(光电隔离)+8路DO(继电器触点)

通信接口:双以太网(1000Mbps)、RS422、光纤通信

2.核心监测与保护逻辑

电力参数分析:

实时计算功率因数、谐波畸变率(THD)、有功/无功功率

支持动态负载平衡监测

故障诊断:

基于AI的异常模式识别,可检测短路、过载、绝缘老化等20+类故障

本地存储50,000条事件日志,支持故障波形分析

3.智能通信与集成能力

协议支持:

工业协议:IEC 61850-3、Modbus RTU/TCP、Profinet

安全机制:支持SSL/TLS加密通信,符合IEC 62443网络安全标准

远程管理:

提供Web HMI界面与移动终端访问功能

支持OTA远程固件升级

技术规格:ALSTOM MCHNM01H1AB0500A 130169520115002

分类: 品牌:

描述

产品简要说明

ALSTOM MCHNM01H1AB0500A 130169520115002是一款工业级电力监测与保护装置,专为中高压电力系统、轨道交通及关键设备设计,核心功能包括:

实时监测:支持电流、电压、温度等多参数高精度采集

智能诊断:集成AI算法,实现故障预判与快速定位

环境适应性:IP67防护等级,适应极端温度与粉尘环境

产品详细说明

1.硬件架构与功能模块

核心处理器:

嵌入式实时操作系统,支持多线程数据处理

支持32位浮点运算,计算精度达±0.05%

输入输出配置:

模拟量输入:8路0-10V/4-20mA输入,支持CT/PT信号适配

数字量I/O:16路DI(光电隔离)+8路DO(继电器触点)

通信接口:双以太网(1000Mbps)、RS422、光纤通信

2.核心监测与保护逻辑

电力参数分析:

实时计算功率因数、谐波畸变率(THD)、有功/无功功率

支持动态负载平衡监测

故障诊断:

基于AI的异常模式识别,可检测短路、过载、绝缘老化等20+类故障

本地存储50,000条事件日志,支持故障波形分析

3.智能通信与集成能力

协议支持:

工业协议:IEC 61850-3、Modbus RTU/TCP、Profinet

安全机制:支持SSL/TLS加密通信,符合IEC 62443网络安全标准

远程管理:

提供Web HMI界面与移动终端访问功能

支持OTA远程固件升级

技术规格:ALSTOM MCHNM01H1AB0500A 130169520115002

参数项规格描述

电源输入24-240V AC/DC,双冗余电源(热备份)

输入通道8路模拟量输入(0-10V/4-20mA)+16路DI+8路DO

通信接口2×1000Mbps以太网+RS422+单模光纤

防护等级IP67(防护等级)

工作温度-40℃至70℃

核心价值与性能亮点

1.AI驱动的智能诊断

技术突破:在数据中心UPS系统中,通过AI算法提前30分钟预警电池老化故障

2.高可靠性设计

场景案例:某地铁牵引变电站中,双冗余电源设计避免因电压波动导致的系统宕机

应对挑战,创造价值

1.复杂电磁环境干扰

技术突破:采用电磁屏蔽外壳与抗干扰滤波电路,在钢铁厂高电磁干扰环境中误报率<0.1%

2.多协议兼容性需求

场景案例:港口自动化码头中,同时支持Modbus与Profinet协议,实现与PLC、SCADA系统无缝对接

Product brief description

ALSTOM MCHNM01H1AB0500A 130169520115002 is an industrial-grade power monitoring and protection device designed for medium and high voltage power systems,rail transit and key equipment.The core functions include:

Real-time monitoring:Supports high-precision acquisition of multi-parameters such as current,voltage,and temperature

Intelligent diagnostics:Integrated AI algorithms to achieve fault prediction and rapid positioning

Environmental adaptability:IP67 protection level,adapt to extreme temperature and dust environments

Product details

1.Hardware architecture and functional modules

Core processor:

Embedded real-time operating system,supports multi-threaded data processing

Supports 32-bit floating point operation,with calculation accuracy up to±0.05%

Input and output configuration:

Analog input:8 channels 0-10V/4-20mA inputs,supporting CT/PT signal adaptation

Digital I/O:16-channel DI(optical isolation)+8-channel DO(relay contact)

Communication interface:Dual Ethernet(1000Mbps),RS422,fiber optic communication

2.Core monitoring and protection logic

Power parameter analysis:

Real-time calculation of power factor,harmonic distortion rate(THD),active/reactive power

Support dynamic load balancing monitoring

Troubleshooting:

AI-based abnormal pattern recognition can detect 20+types of faults such as short circuit,overload,insulation aging,etc.

50,000 event logs are stored locally,supporting fault waveform analysis

3.Intelligent communication and integration capabilities

Protocol support:

Industrial Agreement:IEC 61850-3,Modbus RTU/TCP,Profinet

Security mechanism:Supports SSL/TLS encrypted communication,complies with IEC 62443 network security standard

Remote Management:

Provides Web HMI interface and mobile terminal access functions

Support OTA remote firmware upgrade

Technical specifications:ALSTOM MCHNM01H1AB0500A 130169520115002

Parameters Specification Description

Power input 24-240V AC/DC,dual redundant power supply(hot backup)

Input channel 8 analog inputs(0-10V/4-20mA)+16 DI+8 DO

Communication interface 2×1000Mbps Ethernet+RS422+single-mode fiber

Protection level IP67(Protection level)

Operating temperature-40℃to 70℃

Core Values​​and Performance Highlights

1.AI-driven intelligent diagnosis

Technical breakthrough:In the UPS system of the data center,AI algorithm is used to warn of battery aging failure 30 minutes in advance

2.High reliability design

Scenario case:In a subway traction substation,the dual redundant power supply design avoids system downtime due to voltage fluctuations

Respond to challenges and create value

1.Complex electromagnetic environment interference

Technical breakthrough:Using electromagnetic shielded shell and anti-interference filter circuit,the false alarm rate is<0.1%in high electromagnetic interference environment of steel plants

2.Multi-protocol compatibility requirements

Scenario case:In the port automation terminal,it supports Modbus and Profinet protocols at the same time to achieve seamless connection with PLC and SCADA systems.
