描述
产品简要说明
MAGNETEK MG3-1F-1F-3FE是一款专为工业运动控制领域设计的高性能控制器，核心特性包括：
多轴同步控制：支持4轴独立控制与同步插补，适用于复杂轨迹规划
高精度定位：编码器分辨率支持16位至23位，重复定位精度±0.01mm
多协议兼容：内置EtherCAT、CANopen及Profinet协议，适配主流工业总线
产品详细说明
1.核心技术架构
运动控制算法：
基于FPGA的实时轨迹生成技术，插补周期≤0.1ms
支持S型加减速曲线，减少机械冲击
通信架构：
双EtherCAT主站接口，支持菊花链与星型拓扑混合组网
内置OPC UA服务器，支持工业物联网数据交互
2.硬件设计亮点
电源管理：
双冗余24V DC输入，支持宽压范围（18-36V）
功耗≤15W，效率≥90%
环境适应性：
防护等级IP67，适应油污、潮湿环境
工作温度范围-20℃至60℃（可选配-30℃低温套件）
技术规格:MAGNETEK MG3-1F-1F-3FE
参数项规格描述
CPU频率200MHz
存储容量16MB Flash+512KB RAM
I/O点数8DI（数字输入）、4DO（数字输出）、2AO（模拟输出）
隔离耐压3000V AC（输入/输出）
最大轴数4轴独立控制（支持扩展至8轴）
核心价值与性能亮点
1.高精度控制
案例：在半导体晶圆搬运系统中，实现±0.005mm的定位精度，故障率低于0.001%。
2.智能运维
功能：
实时监测电机电流、温度等参数，支持预测性维护
通过MAGNETEK Studio软件实现一键式参数备份与恢复
Product brief description
MAGNETEK MG3-1F-1F-3FE is a high-performance controller designed for the industrial motion control field,with core features including:
Multi-axis synchronization control:supports 4-axis independent control and synchronous interpolation,suitable for complex trajectory planning
High-precision positioning:The encoder resolution supports 16-bit to 23-bit,repeat positioning accuracy±0.01mm
Multi-protocol compatibility:built-in EtherCAT,CANopen and Profinet protocols,adapted to mainstream industrial buses
Product details
1.Core technology architecture
Motion control algorithm:
Real-time trajectory generation technology based on FPGA,interpolation period≤0.1ms
Support S-type acceleration and deceleration curve to reduce mechanical impact
Communication architecture:
Dual EtherCAT master interface,supports mixed networking of daisy chain and star topology
Built-in OPC UA server,supports industrial IoT data interaction
2.Highlights of hardware design
Power Management:
Dual redundant 24V DC input,support wide voltage range(18-36V)
Power consumption≤15W,efficiency≥90%
Environmental adaptability:
Protection level IP67,adapts to oily and humid environments
Operating temperature range-20℃to 60℃(optional-30℃low temperature kit)
Technical Specifications:MAGNETEK MG3-1F-1F-3FE
Parameters Specification Description
CPU frequency 200MHz
Storage capacity 16MB Flash+512KB RAM
I/O points:8DI(digital input),4DO(digital output),2AO(analog output)
Isolation withstand voltage 3000V AC(input/output)
Maximum number of axes:4-axis independent control(supports expansion to 8-axis)
Core Valuesand Performance Highlights
1.High-precision control
Case:In the semiconductor wafer handling system,the positioning accuracy of±0.005mm is achieved,and the failure rate is less than 0.001%.
2.Intelligent operation and maintenance
Function:
Real-time monitoring of motor current,temperature and other parameters to support predictive maintenance
One-click parameter backup and recovery through MAGNETEK Studio software
