一、产品概述
YOKOGAWA ANR10D是横河（YOKOGAWA）推出的节点接口单元，属于控制系统系列，专为工业自动化网络设计。其核心功能是实现多节点间的高效通信与数据交换，支持与横河DCS（分布式控制系统）无缝集成，适用于恶劣工业环境，广泛应用于制造业、石油天然气、发电及化工等领域。
二、核心功能与技术参数
1.通信能力
高速可靠通信：支持双冗余总线节点单元设计，确保网络通信的稳定性和实时性。
协议兼容性：兼容横河DCS系统的通信协议，支持ER总线（如ANR10D-423型号）或其他工业协议。
2.电源与扩展性
电源选项：
双冗余电源（型号后缀-4）：支持100-120V AC、220-240V AC或24V DC输入，提供双电源冗余。
防爆选项（型号后缀E/F）：符合ISA G3标准，适用于易燃易爆环境。
扩展接口：
支持节点扩展软件许可证（如/NDEL），与AFV30/AFV40系列模块强制连接。
可选配防爆手册（/ATDOC）以满足特殊场景需求。
3.环境适应性
工作温度：-20°C至70°C（防爆型号需额外确认）。
防护等级：适用于粉尘、潮湿及振动环境，满足工业级可靠性要求。
4.物理规格
安装方式：19英寸机架安装（如ANR10D-423型号）。
尺寸与重量：尺寸约458×87×96mm，重量约0.57kg
三、典型应用场景
工业自动化
石油天然气处理、化工生产中的过程控制与数据采集。
电力系统
发电站设备监控、电网稳定性管理。
制造业
生产线设备集成、机器人控制与实时状态监测。
恶劣环境监测
矿山、化工厂等高风险区域的防爆通信节点部署。
YOKOGAWA ANR10D
1.Product Overview
YOKOGAWA ANR10D is a node interface unit launched by Yokogawa(YOKOGAWA).It belongs to the control system series and is specially designed for industrial automation networks.Its core function is to realize efficient communication and data exchange between multiple nodes,support seamless integration with Yokogawa DCS(distributed control system),is suitable for harsh industrial environments,and is widely used in manufacturing,oil and gas,power generation and chemical industries.
2.Core functions and technical parameters
1.Communication capability
High-speed and reliable communication:supports dual redundant bus node unit design to ensure the stability and real-time nature of network communication.
Protocol compatibility:compatible with the communication protocol of Yokogawa DCS system,supports ER bus(such as ANR10D-423 model)or other industrial protocols.
2.Power supply and expansion
Power Options:
Dual redundant power supply(model suffix-4):supports 100-120V AC,220-240V AC or 24V DC inputs,providing dual power supply redundancy.
Explosion-proof options(model suffix E/F):Complies with ISA G3 standards and is suitable for flammable and explosive environments.
Extended interface:
Supports node extension software license(such as/NDEL)and force connection with AFV30/AFV40 series modules.
Optional explosion-proof manual(/ATDOC)is available to meet the needs of special scenarios.
3.Environmental adaptability
Operating temperature:-20°C to 70°C(Extra confirmation is required for explosion-proof models).
Protection level:suitable for dust,humidity and vibration environments,meeting industrial-grade reliability requirements.
4.Physical specifications
Installation method:19-inch rack installation(such as ANR10D-423 model).
Dimensions and weight: about 458×87×96mm,weight is about 0.57kg
3.Typical application scenarios
Industrial automation
Process control and data collection in oil and gas treatment and chemical production.
Power system
Power station equipment monitoring and grid stability management.
manufacturing
Production line equipment integration,robot control and real-time status monitoring.
Harsh environment monitoring
Deployment of explosion-proof communication nodes in high-risk areas such as mines and chemical plants.
