HOMER UEM5-100技术数据解析
UEM5-100是HOMER公司生产的塑料外壳式断路器（含漏电保护功能），适用于低压配电系统，具备多级保护与智能化设计。以下是其核心技术数据：
一、基础参数
额定电流
壳架电流：100A（支持分断能力分级：标准型、较高分断型、高分断型、限流型）。
额定工作电流：6A至100A（具体型号可能不同，如UEM5-100L/63-3300的额定电流为63A）。
电压规格
额定工作电压：415V AC（50Hz）。
额定绝缘电压：800V。
分断能力
短路分断能力：
标准型（L）：35kA（如UEM5-100L/63-3300）。
较高分断型（M）：更高分断能力（具体数值需参考型号）。
二、保护功能
核心保护
过载保护：通过热磁式脱扣器实现。
短路保护：电磁脱扣器快速切断故障电流。
欠电压保护：线电压低至50V时仍可触发保护。
漏电保护（UEM5L系列）：
剩余动作电流可调（如30mA、100mA等）。
动作时间支持非延时与延时调节。
附加保护
分励脱扣器：支持远程控制分闸，兼容AC220V/415V或DC24V/110V电压。
报警触头：实时反馈过载、短路或欠电压故障状态。
三、结构与设计
材料与外壳
外壳材质：美国IDI热固性复合材料压制，具备高绝缘性与机械强度。
防护等级：IP20（封闭型），部分型号支持IP65（如带快速装卸接头的版本）。
触头系统
电磁斥力限流设计：故障电流时触头迅速斥开，避免电弧重燃，提升分断能力。
动平衡优化：峰-峰值动平衡≤0.0127mm，确保运行稳定性。
安装与扩展
安装方式：板前/板后接线、插入式接线，支持导轨安装。
附件兼容性：可加装辅助触头、欠电压脱扣器等，无需拆盖即可安装。
HOMER UEM5-100 Technical data analysis
UEM5-100 is a plastic shell circuit breaker(including leakage protection function)produced by HOMER.It is suitable for low-voltage power distribution systems and has multi-level protection and intelligent design.The following are its core technical data:
1.Basic parameters
Rated current
Shell current:100A(supports breaking capacity classification:standard type,higher breaking type,high breaking type,current limiting type).
Rated operating current:6A to 100A(specific models may vary,such as 63A rated for UEM5-100L/63-3300).
Voltage specifications
Rated operating voltage:415V AC(50Hz).
Rated insulation voltage:800V.
Break-off capability
Short circuit breaking capability:
Standard type(L):35kA(such as UEM5-100L/63-3300).
Higher breaking type(M):Higher breaking ability(specific valuesrequire reference model).
2.Protection function
Core protection
Overload protection:achieved through a thermomagnetic tripper.
Short circuit protection:The electromagnetic tripper quickly cuts off the fault current.
Undervoltage protection:Protection can still be triggered when line voltage is as low as 50V.
Leakage protection(UEM5L series):
The remaining operation current is adjustable(such as 30mA,100mA,etc.).
The action time supports non-delay and delay adjustment.
Additional protection
Excitation tripper:Supports remote control opening and is compatible with AC220V/415V or DC24V/110V voltage.
Alarm contact:Real-time feedback of overload,short circuit or undervoltage fault status.
III.Structure and Design
Material and shell
Shell material:pressed by IDI thermoset composite material,with high insulation and mechanical strength.
Protection level:IP20(closed type),some models support IP65(such as versions with quick loading and unloading connectors).
Contact system
Electromagnetic repulsive current limit design:the contact repels quickly during fault current to avoid arc reignitment and improve breakage capability.
Dynamic balance optimization:Peak-peak dynamic balance≤0.0127mm to ensure operational stability.
Installation and Extension
Installation method:front/back of the board,plug-in wiring,support rail installation.
Accessories compatibility:Auxiliary contacts,undervoltage trippers,etc.can be installed without removing the cover.
