GE IC695CPU320-CF产品详情
一、产品概述
GE IC695CPU320-CF是GE Intelligent Platform（现属艾默生自动化解决方案）推出的PACSystems RX3i系列高性能可编程自动化控制器（PAC）。该型号属于CPU320系列，配备CompactFlash（CF）卡存储扩展，专为工业自动化控制、过程监控及数据采集设计，支持分布式控制架构，适用于离散制造、过程工业、能源管理等复杂场景。
二、核心硬件规格
1.处理器性能
CPU类型：
采用Intel Celeron M处理器（主频1.0GHz），具备32位运算能力，支持浮点运算，可满足高速逻辑控制与复杂算法需求。
内存配置：
内置RAM****：128MB（用于程序运行及临时数据存储）。
用户存储：通过CompactFlash卡槽支持最高2GB CF卡（需用户自行配置），用于存储程序、历史数据及配方。
2.I/O扩展能力
本地I/O容量：
支持最多12个本地I/O模块（通过RX3i机架背板连接），涵盖数字量（DI/DO）、模拟量（AI/AO）、温度、运动控制等类型。
远程I/O扩展：
通过EtherNet/IP、PROFIBUS-DP、Modbus TCP/RTU等协议连接远程I/O站（如GE SRM系列或第三方设备），单控制器最多可管理1024个I/O点。
3.通信接口
以太网端口：
2个10/100Mbps RJ45端口，支持双IP地址配置，可实现冗余通信或多网络隔离。
支持EtherNet/IP、Modbus TCP、PROFINET IO等工业协议，便于与HMI、SCADA、MES系统集成。
串行通信端口：
1个RS-232/RS-485可选端口，支持Modbus RTU、DF1等协议，用于连接旧设备或调试工具。
USB接口：
1个USB 2.0端口，用于程序下载、固件升级或连接USB存储设备。
三、软件与编程支持
1.开发环境
Proficy Machine Edition（PME）：
GE官方集成开发环境，支持梯形图（LD）、功能块图（FBD）、结构化文本（ST）、顺序功能图（SFC）等IEC 61131-3标准编程语言。
提供在线调试、变量监控、历史趋势分析等功能，简化程序开发与故障排查。
2.操作系统与实时性
VxWorks实时操作系统：
确保确定性控制，任务调度周期≤1ms，满足高速运动控制、闭环调节等实时性要求。
多任务处理能力：
支持64个优先级任务，可同时运行逻辑控制、运动控制、数据处理等任务，互不干扰。
GE IC695CPU320-CF Product Details
I.Product Overview
GE IC695CPU320-CF is a PACSystems RX3i series high-performance programmable automation controller(PAC)launched by GE Intelligent Platform(now Emerson Automation Solutions).This model belongs to the CPU320 series and is equipped with CompactFlash(CF)card storage expansion.It is designed for industrial automation control,process monitoring and data acquisition,supports distributed control architecture,and is suitable for complex scenarios such as discrete manufacturing,process industry,and energy management.
II.Core Hardware Specifications
1.Processor Performance
CPU Type:
Adopts Intel Celeron M processor(main frequency 1.0GHz),has 32-bit computing power,supports floating-point operations,and can meet the needs of high-speed logic control and complex algorithms.
Memory Configuration:
Built-in RAM****:128MB(for program operation and temporary data storage).
User Storage:Supports up to 2GB CF card(user-configured)through CompactFlash card slot for storing programs,historical data and recipes.
2.I/O expansion capability
Local I/O capacity:
Supports up to 12 local I/O modules(connected via the RX3i rack backplane),covering digital(DI/DO),analog(AI/AO),temperature,motion control and other types.
Remote I/O expansion:
Connect remote I/O stations(such as GE SRM series or third-party devices)through protocols such as EtherNet/IP,PROFIBUS-DP,Modbus TCP/RTU,and a single controller can manage up to 1024 I/O points.
3.Communication interface
Ethernet port:
2 10/100Mbps RJ45 ports,supporting dual IP address configuration,which can achieve redundant communication or multi-network isolation.
Supports industrial protocols such as EtherNet/IP,Modbus TCP,PROFINET IO,etc.,which is easy to integrate with HMI,SCADA,and MES systems.
Serial communication port:
1 RS-232/RS-485 optional port,supporting Modbus RTU,DF1 and other protocols,used to connect old devices or debugging tools.
USB interface:
1 USB 2.0 port,used for program download,firmware upgrade or connecting USB storage devices.
III.Software and programming support
1.Development environment
Proficy Machine Edition(PME):
GE official integrated development environment,supporting IEC 61131-3 standard programming languages such as ladder diagram(LD),function block diagram(FBD),structured text(ST),sequential function chart(SFC).
Provides online debugging,variable monitoring,historical trend analysis and other functions to simplify program development and troubleshooting.
2.Operating system and real-time performance
VxWorks real-time operating system:
Ensures deterministic control,task scheduling cycle≤1ms,and meets real-time requirements such as high-speed motion control and closed-loop regulation.
Multi-tasking capability:
Supports 64 priority tasks,and can run logic control,motion control,data processing and other tasks simultaneously without interfering with each other.
