描述
产品简要说明
MAGNETEK DRIVE A5-110-001是一款面向中小型自动化系统的紧凑型工业PLC控制器，核心特性包括：
高密度I/O集成：本体支持16点数字量输入/8点输出，扩展模块支持模拟量与特殊功能
多协议兼容：内置Modbus RTU、Profinet及EtherNet/IP协议，支持跨平台通信
实时控制性能：扫描周期≤0.5ms，适用于高速分拣、包装等动态场景
产品详细说明
1.核心控制架构
双核处理单元：
主控芯片：32位ARM Cortex-M7（主频200MHz）
协处理器：FPGA加速逻辑运算，降低CPU负载
内存配置：
程序存储：1MB Flash（支持在线更新）
数据存储：256KB RAM（支持断电数据保护）
2.硬件设计优势
紧凑尺寸：
体积：90×110×80mm（含散热片）
安装方式：DIN导轨/壁挂双模式
环境适应性：
防护等级IP20（标准）
工作温度范围0℃至55℃（可选配高温套件至70℃）
技术规格:MAGNETEK DRIVE A5-110-001
参数项规格描述
CPU类型32位ARM Cortex-M7
通信接口2×RS485、1×EtherNet/IP、1×Profinet DP
本体I/O 16DI（DC 24V）、8DO（继电器/晶体管可选）
扩展能力最大支持4个扩展模块（总I/O点数≤64DI/32DO）
电源输入24V DC（波动范围18-36V）
核心价值与性能亮点
1.高效控制
案例：在某食品包装线中，通过高速扫描能力实现每分钟120包的精准分拣，效率提升40%。
2.模块化扩展
优势：
支持模拟量模块（4-20mA/0-10V）与特殊功能模块（温度传感器、编码器接口）
模块热插拔设计，无需断电维护
3.行业适配性
应用：
食品加工：兼容HACCP标准，支持多级消毒流程控制
物流分拣：内置运动控制指令库，支持传送带同步定位
Product brief description
MAGNETEK DRIVE A5-110-001 is a compact industrial PLC controller for small and medium-sized automation systems,with core features including:
High-density I/O integration:the body supports 16-point digital input/8-point output,and the expansion module supports analog and special functions
Multi-protocol compatibility:built-in Modbus RTU,Profinet and EtherNet/IP protocols,supports cross-platform communication
Real-time control performance:scan period≤0.5ms,suitable for dynamic scenarios such as high-speed sorting and packaging
Product details
1.Core control architecture
Dual-core processing unit:
Main control chip:32-bit ARM Cortex-M7(main frequency 200MHz)
Coprocessor:FPGA accelerates logic operations and reduces CPU load
Memory configuration:
Program storage:1MB Flash(supports online update)
Data storage:256KB RAM(supports power-off data protection)
2.Hardware design advantages
Compact size:
Volume:90×110×80mm(including heat sink)
Installation method:DIN rail/wall-mounted dual mode
Environmental adaptability:
Protection level IP20(standard)
Operating temperature range 0℃to 55℃(optional high temperature kit to 70℃)
Technical Specifications:MAGNETEK DRIVE A5-110-001
Parameters Specification Description
CPU type 32-bit ARM Cortex-M7
Communication interface 2×RS485,1×EtherNet/IP,1×Profinet DP
Body I/O 16DI(DC 24V),8DO(relay/transistor optional)
Expansion capability:Supports up to 4 expansion modules(total I/O points≤64DI/32DO)
Power input 24V DC(volatility range 18-36V)
Core Valuesand Performance Highlights
1.Efficient control
Case:In a certain food packaging line,accurate sorting of 120 packs per minute is achieved through high-speed scanning capabilities,and the efficiency is increased by 40%.
2.Modular expansion
Advantages:
Supports analog module(4-20mA/0-10V)and special function modules(temperature sensor,encoder interface)
Module hot-swap design,no power outage maintenance required
3.Industry adaptability
application:
Food processing:Compatible with HACCP standard and supports multi-level disinfection process control
Logistics sorting:built-in motion control instruction library,supporting synchronous positioning of conveyor belts
