安川CP-317/217IF通信模块产品详情
该模块扩展了CP-9200SH机器控制器的连接能力，该控制器本身是一个集成了顺序控制器(PLC)和运动控制的集成系统。
类型：通信模块
系列：专为安川CP-9200SH系列机器控制器设计。
主要特性和功能：
多协议支持：217IF模块的一大优势在于它支持各种通信协议，使其能够灵活地集成到不同的工业网络中。这些协议包括：
安川的标准MEMOBUS通信协议。
MELSEC通信协议：用于与三菱电机株式会社的控制器无缝连接。
欧姆龙通信协议：用于与欧姆龙株式会社的可编程逻辑控制器通信。
串行通信接口：该模块通常包含多条串行通信线路，通常具有以下特性：
两个RS-232端口
一个RS-422/485端口
这些接口允许与各种设备进行点对点或多点通信。
数据转换：217IF模块可处理消息转换过程，例如在MEMOBUS和MELSEC消息之间进行转换。这简化了用户的编程，因为用户应用程序无需直接识别外部消息配置。用户可以使用简单的函数（例如MSG-SND和MSG-RCV）并指定传输协议。
诊断LED：该模块通常具有LED指示灯以显示其运行状态：
RUN LED：模块正常运行时亮起。
ERR LED：亮起或闪烁表示出现故障或错误。
TX1、TX2、TX3 LED：指示相应通信线路上的数据传输或接收活动。
系统扩展：作为CP-9200SH系统的模块化组件，它允许用户根据需要扩展其机器控制设置的通信功能。
坚固的工业设计：专为承受典型工业条件而设计，确保在严苛环境下实现可靠通信。
技术规格（典型值）：
尺寸：约2.2厘米x 12.4厘米x 12.6厘米。
重量：约0.1公斤（或1.5公斤，具体取决于具体来源/包装）。
原产国：通常列为美国。
Yaskawa CP-317/217IF Communication Module Product Details
This module extends the connectivity of the CP-9200SH machine controller,which itself is an integrated system combining sequence(PLC)and motion control.
Type:Communication Module
Series:Designed for the Yaskawa CP-9200SH Series Machine Controllers.
Key Features and Functions:
Multi-Protocol Support:A key feature of the 217IF module is its support for various communication protocols,making it highly versatile for integration into different industrial networks.This includes:
Yaskawa’s standard MEMOBUS communications protocol.
MELSEC communications protocol:For seamless connection with Mitsubishi Electric Corporation controllers.
OMRON communications protocol:For communication with OMRON Corporation Programmable Logic Controllers.
Serial Communication Interfaces:The module typically includes multiple serial communication lines,often featuring:
Two RS-232 ports
One RS-422/485 port
These interfaces allow for point-to-point or multi-drop communication with a wide range of devices.
Data Conversion:The 217IF module handles message conversion processes,for example,between MEMOBUS and MELSEC messages.This simplifies programming for users,as there’s no need for the user application to directly recognize the foreign message configurations.Users can utilize simple functions(like MSG-SND and MSG-RCV)and specify the transmission protocol.
Diagnostic LEDs:The module typically features LED indicators to show its operational status:
RUN LED:Illuminates when the module is operating normally.
ERR LED:Lights up or blinks to indicate a fault or error condition.
TX1,TX2,TX3 LEDs:Indicate data transmission or reception activity on the respective communication lines.
System Expansion:As a modular component of the CP-9200SH system,it allows users to expand the communication capabilities of their machine control setup as needed.
Robust Industrial Design:Built to withstand typical industrial conditions,ensuring reliable communication in challenging environments.
Technical Specifications(Typical):
Dimensions:Approximately 2.2 cm x 12.4 cm x 12.6 cm.
Weight:Around 0.1 kg(or 1.5 kg depending on the exact source/packaging).
Country of Origin:Often listed as USA.
