描述
施耐德140DDO84300是Modicon Quantum系列中的离散量输出模块。主要用于将PLC的数字信号转换为直流电压信号，以驱动继电器、电磁阀、指示灯等外部设备。以下是其产品详情：
输出通道：16个。
输出电压范围：10至60V DC。
输出电流：每通道最大2A。
响应时间：≤1毫秒。
保护机制：内置8A熔断器保护。
工作温度范围：-20°C至+60°C。
存储温度范围：-40°C至+85°C。
防护等级：IP20。
重量：约0.99kg。
通信协议：支持Modbus等协议。
安装方式：DIN导轨安装。
功率消耗：最大功率为1W+(1 x总模块负载电流)x VDC。
The Schneider 140DDO84300 is a discrete output module in the Modicon Quantum series.It is primarily used to convert PLC digital signals into DC voltage signals to drive external devices such as relays,solenoid valves,and indicator lights.Product details are as follows:
Output channels:16.
Output voltage range:10 to 60V DC.
Output current:Maximum 2A per channel.
Response time:≤1 millisecond.
Protection:Built-in 8A fuse.
Operating temperature range:-20°C to+60°C.
Storage temperature range:-40°C to+85°C.
Protection rating:IP20.
Weight:Approximately 0.99kg.
Communication protocols:Supports Modbus and other protocols.
Mounting method:DIN rail mount.
Power consumption:Maximum power consumption is 1W+(1 x total module load current)x VDC.
