描述
施耐德140XBE10000是Modicon Quantum系列的背板扩展模块。以下是其产品详情：
功能用途：用于本地和远程I/O节点的第二基板扩展，可使Quantum CPU支持到27,648离散量I/O点。能节省在节点处扩展I/O模块的费用，提升Quantum系统在少节点大点数情况下的性能价格比，还可提升整个系统的性能。
扩展方式：两个Quantum模块和一根电缆可支持本地和远程I/O的节点在第二个基板上进行I/O模块配置。电缆有3英尺、6英尺和9英尺长三种尺寸。
支持模块：支持所有现有的Quantum I/O模块，包括所有数字量和模拟量I/O模块、两种高速计数器等。
配置要求：在Proworx中需要作I/O Map配置，但在Concept和Modsoft中不需要作I/O Map配置。
功能特点：
高速通信：支持10/100M以太网通讯，具备TCP/IP协议栈，可实现PLC与其他设备之间的高速数据交换。
多种接口：提供RJ45接口，支持10BASE-T/100BASE-TX绞合线对以及MT/RJ 100BASE-FX光纤传输。
远程配置：集成嵌入式HTTP服务器，支持通过Web浏览器进行远程访问和配置，方便用户进行设备监控和管理。
编辑查看：内置数据编辑器和机架查看器功能，便于用户对PLC程序和数据进行编辑和查看。
带宽管理：支持带宽管理功能，可根据实际需求分配网络带宽资源。
The Schneider 140XBE10000 is a backplane expansion module for the Modicon Quantum series.Product details are as follows:
Function:Used to expand local and remote I/O nodes with a second baseboard,it increases the Quantum CPU’s support to 27,648 discrete I/O points.This saves the cost of adding I/O modules at the node level,improving the cost-performance of a Quantum system with fewer nodes and a larger number of points,and also boosting overall system performance.
Expansion Method:Two Quantum modules and one cable support local and remote I/O nodes on a second baseboard.Cables are available in 3-foot,6-foot,and 9-foot lengths.
Supported Modules:Supports all existing Quantum I/O modules,including all digital and analog I/O modules,two high-speed counters,and more.
Configuration Requirements:I/O Map configuration is required in Proworx,but not in Concept and Modsoft.Features:
High-speed Communication:Supports 10/100M Ethernet communication and features a TCP/IP protocol stack,enabling high-speed data exchange between PLCs and other devices.
Multiple Interfaces:Provides an RJ45 interface,supporting 10BASE-T/100BASE-TX twisted-pair wiring and MT/RJ 100BASE-FX fiber optic transmission.
Remote Configuration:An integrated embedded HTTP server supports remote access and configuration via a web browser,facilitating device monitoring and management.
Editing and Viewing:Built-in data editor and rack viewer functions facilitate editing and viewing of PLC programs and data.
Bandwidth Management:Supports bandwidth management to allocate network bandwidth resources based on actual needs.
