描述
本特利3300/16-14-01-03-00-00-01是一款通用设备监控器。以下是其产品详情：
基本参数
重量：2.5KG。
通信协议：支持Ethernet/IP、Profinet等多种工业标准通信协议。
输入输出配置
输入：提供四个传感器输入和四个温度输入。软件可配置每个传感器输入，以支持2线和3线加速度计、速度传感器或近程传感器。每个温度输入都支持E、J、K和T型热电偶，以及双线或三线RTD。
输出：提供六个继电器输出、四个4-20mA记录器输出和一个专用缓冲输出。继电器操作是可编程的，用户可以根据任何通道或通道组合的正常、报警和危险状态打开或关闭继电器触点，并在任何记录仪输出上提供任何通道的任何变量的数据。
功能特点
数据处理与传输：具备高效的数据包处理机制，可快速、准确地在不同网络节点间传输数据，适合大数据量的实时通信场景。
网络特性：具备网络冗余功能，在网络部分组件出现故障时，能保持数据传输的连续性和完整性。同时提供加密通信选项，保障数据传输安全。
配置方式：用户可以通过软件界面轻松配置模块的网络参数，如IP地址、子网掩码等。用户使用笔记本电脑或PC上运行的软件创建配置文件，并通过内置的以太网连接将文件下载到监视器，从而定义监视器操作和Modbus网关寄存器映射。
其他功能：支持可选的显示器/键盘，以查看频道信息或进行较小的配置更改，使得该监控器可以作为独立组件运行。
The Bentley 3300/16-14-01-03-00-00-01 is a general-purpose equipment monitor.Product details are as follows:
Basic Parameters
Weight:2.5 kg
Communication Protocols:Supports various industry-standard communication protocols,including Ethernet/IP and Profinet.
Input and Output Configuration
Inputs:Provides four sensor inputs and four temperature inputs.Each sensor input is software-configurable to support 2-wire and 3-wire accelerometers,velocity sensors,or proximity sensors.Each temperature input supports E-,J-,K-,and T-type thermocouples,as well as 2-wire and 3-wire RTDs.
Outputs:Provides six relay outputs,four 4-20 mA recorder outputs,and one dedicated buffered output.Relay operation is programmable,allowing users to open or close relay contacts based on the normal,alarm,and danger states of any channel or channel combination,and provide data from any variable on any channel on any recorder output.Features
Data Processing and Transmission:Equipped with an efficient packet processing mechanism,the monitor can quickly and accurately transmit data between different network nodes,making it suitable for real-time communication scenarios with large data volumes.
Network Features:Network redundancy ensures the continuity and integrity of data transmission in the event of a network component failure.Encrypted communication options are also available to ensure data transmission security.
Configuration:The user can easily configure the module’s network parameters,such as IP address and subnet mask,through a software interface.Users create configuration files using software running on a laptop or PC and download them to the monitor via the built-in Ethernet connection to define monitor operation and the Modbus gateway register map.
Additional Features:Support for an optional display/keyboard is provided for viewing channel information or making minor configuration changes,allowing the monitor to operate as a standalone component.
