描述
本特利内华达330180-X0-05产品详情
这款前置器传感器属于先进的3300 XL系列，相比之前的设计，性能和可靠性均有所提升。
类型：前置器传感器（也称为接近传感器或信号调节器）。
系列：3300 XL系列。
功能：该电子元件将来自接近探头和延长电缆的高频电压转换为直流电压输出，该电压输出与探头尖端与被观察导电表面（例如旋转轴）之间的距离成正比。该输出电压可用于测量静态（位置）和动态（振动）值。
主要特性和功能：
非接触式测量：可对旋转机械的位移、振动和轴位置进行非接触式测量。
探头兼容性：可容纳一个非接触式Bently Nevada 3300系列5毫米或3300 XL 8毫米电涡流探头及延长线。系统（探头、延长线和前置器传感器）完全可互换，这意味着您无需单独匹配或校准单个组件。
高性能：
线性范围：通常为2毫米（80密耳），提供与间隙对应的线性输出电压。
精度：振动和位置测量精度高。
灵敏度：输出电阻为50Ω，输入电压每变化1伏，输出电压变化小于2毫伏。
坚固耐用的结构：采用A308铝等耐用材料制成，可承受恶劣的工业环境。
宽工作温度范围：可在-51°C至+100°C（-60°F至+212°F）范围内有效工作，适用于各种工业应用。
射频干扰(RFI)/电磁干扰(EMI)抗扰度：增强了对射频干扰(RFI)和电磁干扰(EMI)的抗扰度，可安装在各种类型的外壳中，且不会受到附近信号的不利影响。这有助于满足欧洲CE标志认证，无需特殊屏蔽导管。
电源：需要-17.5 Vdc至-26 Vdc（最大功耗12 mA）。
安装选项：零件编号中的“X0”表示系统长度为1.0米（3.3英尺），并采用面板安装配置。另有其他长度和DIN导轨安装选项可供选择。
机构认证：后缀“05”通常表示已获得多项认证，包括CSA、ATEX和IECEx，因此适用于危险(Ex)区域。
向后兼容性：完全向后兼容并可与其他非XL 3300系列5毫米和8毫米传感器系统组件互换。
Bently Nevada 330180-X0-05 Product Details
This Proximitor sensor is part of the advanced 3300 XL series,offering improved performance and reliability over previous designs.
Type:Proximitor Sensor(also known as a Proximity Sensor or Signal Conditioner).
Series:3300 XL Series.
Function:It’s the electronic component that converts the high-frequency voltage from a proximity probe and extension cable into a DC voltage output that is directly proportional to the distance between the probe tip and the observed conductive surface(e.g.,a rotating shaft).This output voltage can then be used to measure both static(position)and dynamic(vibration)values.
Key Features and Functions:
Non-Contact Measurement:Provides non-contact measurement of displacement,vibration,and shaft position on rotating machinery.
Probe Compatibility:Accepts one non-contacting Bently Nevada 3300-series 5 mm,3300 XL 8 mm Proximity Probe and Extension Cable.The system(probe,extension cable,and Proximitor sensor)is fully interchangeable,meaning you don’t need to match or bench calibrate individual components.
High Performance:
Linear Range:Typically 2 mm(80 mils),providing a linear output voltage corresponding to the gap.
Accuracy:High precision for vibration and position measurements.
Sensitivity:Output resistance of 50Ω,with sensitivity less than 2 mV change in output voltage per volt change in input voltage.
Robust Construction:Made from durable materials like A308 aluminum,designed to withstand harsh industrial environments.
Wide Operating Temperature Range:Operates effectively between-51°C to+100°C(-60°F to+212°F),making it suitable for a broad range of industrial applications.
RFI/EMI Immunity:Incorporates improved immunity to radio frequency interference(RFI)and electromagnetic interference(EMI),allowing for installation in various housing types without adverse effects from nearby signals.This helps satisfy European CE mark approvals without requiring special shielded conduit.
Power Supply:Requires-17.5 Vdc to-26 Vdc(maximum consumption of 12 mA).
Mounting Options:The”X0″in the part number indicates a 1.0-meter(3.3 feet)system length and panel mount configuration.Other options exist for different lengths and DIN rail mounting.
Agency Approvals:The”05″suffix typically denotes multiple approvals,including CSA,ATEX,and IECEx,making it suitable for use in hazardous(Ex)areas.
Backward Compatibility:Fully backward-compatible and interchangeable with other non-XL 3300 series 5 mm and 8 mm transducer system components.
