描述
Bently Nevada 330100-90-00产品详情解析。该型号属于3300 XL系列电涡流位移传感器系统的高性能套件，通常包含探头、延伸电缆、前置器及安装附件，专为旋转机械的振动、位移、胀差等关键参数监测设计，广泛应用于电力、油气、化工等行业的核心设备（如汽轮机、发电机、压缩机等）：
一、产品概述
型号：330100-90-00
品牌：Bently Nevada（贝克休斯旗下，工业状态监测领域领导者）
系列：3300 XL系列（高性能电涡流传感器系统）
核心功能：
非接触式测量转子与探头端面的动态间隙，实时监测振动、轴向位移、胀差等参数。
兼容Bently Nevada 3300/3500/4000系列监测系统及System 1软件，支持预测性维护与故障诊断。
适用于高温、高振动、强电磁干扰等严苛工业环境。
二、系统组成与核心组件
330100-90-00为完整传感器套件，通常包含以下组件（具体配置可能因订单要求调整）：
1.探头（Proximity Probe）
型号：3300 XL 8mm或11mm（根据量程需求选择）。
功能：
非接触式测量转子与探头端面的动态间隙，反映设备振动、位移等状态。
关键特性：
高精度测量：
分辨率：≤0.1μm（典型值），满足精密监测需求。
线性度：≤±1%全量程，确保数据准确性。
耐温设计：
标准型号：-35℃至+175℃（探头头部）。
高温型号（HT）：-35℃至+260℃（适用于汽轮机高温段）。
抗振动干扰：
探头结构强化，适应高振动环境（振动幅度>500μm）。
防爆认证：
ATEX/IECEx Zone 0/1/2认证（可选），适用于油气、化工等危险区域。
材料与防护：
探头头部：Inconel 600合金（耐腐蚀、耐高温）。
外壳：不锈钢316L（防锈、抗化学侵蚀）。
防护等级：IP68（防尘防水，可短期浸没）。
Bently Nevada 330100-90-00 Product Details.This model is a high-performance kit for the 3300 XL Series eddy-current displacement sensor system.It typically includes a probe,extension cable,proximitor sensor,and mounting accessories.It is designed specifically for monitoring key parameters such as vibration,displacement,and differential expansion in rotating machinery.It is widely used in core equipment(such as turbines,generators,and compressors)in the power,oil and gas,and chemical industries.
I.Product Overview
Model:330100-90-00
Brand:Bently Nevada(a Baker Hughes company,a leader in industrial condition monitoring)
Series:3300 XL Series(High-Performance Eddy-Current Sensor System)
Core Functions:
Non-contact measurement of the dynamic clearance between the rotor and the probe tip,providing real-time monitoring of parameters such as vibration,axial displacement,and differential expansion.
Compatible with the Bently Nevada 3300/3500/4000 Series Monitoring Systems and System 1 software,supporting predictive maintenance and fault diagnosis.Suitable for harsh industrial environments such as those subject to high temperature,high vibration,and strong electromagnetic interference.
II.System Composition and Core Components
The 330100-90-00 is a complete sensor kit,typically including the following components(specific configuration may vary depending on order requirements):
1.Proximity Probe
Model:3300 XL,8mm or 11mm(selectable based on range requirements).
Function:
Non-contact measurement of the dynamic clearance between the rotor and the probe end face,reflecting equipment vibration,displacement,and other conditions.
Key Features:
High-Precision Measurement:
Resolution:≤0.1μm(typical),meeting precision monitoring needs.
Linearity:≤±1%of full scale,ensuring data accuracy.
Temperature-Resistant Design:
Standard Model:-35°C to+175°C(probe head).
High-Temperature Model(HT):-35°C to+260°C(suitable for high-temperature sections of steam turbines).Vibration Resistance:
The probe’s reinforced structure withstands high-vibration environments(vibration amplitude>500μm).
Explosion-Proof Certification:
ATEX/IECEx Zone 0/1/2 certification(optional)makes it suitable for hazardous areas such as oil,gas,and chemical industries.
Material and Protection:
Probe head:Inconel 600 alloy(corrosion-resistant and high-temperature resistant).
Casing:316L stainless steel(rust-resistant and chemical-resistant).
Protection Rating:IP68(dustproof and waterproof,withstanding short-term immersion).
