描述
Bently Nevada 330103-00-09-10-02-00产品详情解析。该型号属于3300 XL系列电涡流位移传感器系统的高性能套件，专为旋转机械的振动、位移、胀差等关键参数监测设计，广泛应用于电力、油气、化工等行业的核心设备（如汽轮机、发电机、压缩机等）。以下是详细信息：
一、产品概述
型号：330103-00-09-10-02-00
品牌：Bently Nevada（贝克休斯旗下，工业状态监测领域领导者）
系列：3300 XL系列（高性能电涡流传感器系统）
核心功能：
非接触式测量转子与探头端面的动态间隙，实时监测振动、轴向位移、胀差等参数。
兼容Bently Nevada 3300/3500/4000系列监测系统及System 1软件，支持预测性维护与故障诊断。
适用于高温、高振动、强电磁干扰等严苛工业环境。
二、型号分解与配置说明
Bently Nevada的型号编码通常包含关键参数信息。以330103-00-09-10-02-00为例：
330103：基础型号，表示3300 XL系列电涡流传感器套件。
00：探头类型（标准型，非高温或特殊材质）。
09：探头量程（9mm，即测量范围0.25mm至9mm）。
10：延伸电缆长度（10英尺，约3.05米）。
02：前置器类型（标准型，非防爆或特殊功能）。
00：附加选项（无特殊配置，如校准证书或特殊包装）。
三、系统组成与核心组件
330103-00-09-10-02-00为完整传感器套件，包含以下组件：
1.探头（Proximity Probe）
型号：3300 XL 9mm探头。
功能：
非接触式测量转子与探头端面的动态间隙，反映设备振动、位移等状态。
关键特性：
高精度测量：
分辨率：≤0.1μm（典型值），满足精密监测需求。
线性度：≤±1%全量程（0.25mm至9mm）。
耐温设计：
标准型号：-35℃至+175℃（探头头部），适用于大多数工业环境。
抗振动干扰：
探头结构强化，适应高振动环境（振动幅度>500μm）。
材料与防护：
探头头部：Inconel 600合金（耐腐蚀、耐高温）。
外壳：不锈钢316L（防锈、抗化学侵蚀）。
防护等级：IP68（防尘防水，可短期浸没）。
Bently Nevada 330103-00-09-10-02-00 Product Details.This model is part of the high-performance suite of the 3300 XL Series eddy-current displacement sensor systems.Designed specifically for monitoring key parameters of rotating machinery,such as vibration,displacement,and differential expansion,it is widely used in core equipment(such as turbines,generators,and compressors)in the power,oil and gas,and chemical industries.The following are details:
I.Product Overview
Model:330103-00-09-10-02-00
Brand:Bently Nevada(a Baker Hughes company,a leader in industrial condition monitoring)
Series:3300 XL Series(High-Performance Eddy-Current Sensor System)
Core Functions:
Non-contact measurement of the dynamic clearance between the rotor and the probe tip,providing real-time monitoring of parameters such as vibration,axial displacement,and differential expansion.
Compatible with the Bently Nevada 3300/3500/4000 Series Monitoring Systems and System 1 software,supporting predictive maintenance and fault diagnosis.Suitable for harsh industrial environments such as those with high temperatures,high vibration,and strong electromagnetic interference.
II.Model Decomposition and Configuration Instructions
Bently Nevada model codes typically contain key parameter information.For example,330103-00-09-10-02-00:
330103:Basic model,representing the 3300 XL Series Eddy Current Sensor Kit.
00:Probe type(standard,not high-temperature or made of special materials).
09:Probe range(9mm,measuring range 0.25mm to 9mm).
10:Extension cable length(10 feet,approximately 3.05 meters).
02:Proximitor sensor type(standard,not explosion-proof or with special features).
00:Additional options(no special configurations,such as calibration certificates or special packaging).
III.System Composition and Core Components
The 330103-00-09-10-02-00 sensor kit includes the following components:
1.Proximity Probe
Model:3300 XL 9mm probe.
Function:
Non-contact measurement of the dynamic clearance between the rotor and the probe tip,reflecting equipment vibration,displacement,and other conditions.
Key Features:
High-Precision Measurement:
Resolution:≤0.1μm(typical),meeting precision monitoring requirements.
Linearity:≤±1%of full scale(0.25mm to 9mm).
Temperature-Resistant Design:
Standard model:-35°C to+175°C(probe head),suitable for most industrial environments.
Vibration Resistance:
Reinforced probe structure for high-vibration environments(vibration amplitude>500μm).
Material and Protection:
Probe head:Inconel 600 alloy(corrosion-resistant and high-temperature resistant).Housing:316L stainless steel(rust-resistant and chemical-resistant).
Ingress protection:IP68(dustproof and waterproof,withstands short-term immersion).
