描述
Bently Nevada 330103-00-15-10-02-00产品详情解析。该型号属于3300 XL系列电涡流位移传感器系统的高性能套件，与之前介绍的330103-00-10-50-02-00类似，但在量程和延伸电缆长度上进一步优化，适用于超大位移监测和超长距离信号传输的工业场景（如大型汽轮机、发电机、长轴系设备等）。以下是详细信息：
一、产品概述
型号：330103-00-15-10-02-00
品牌：Bently Nevada（贝克休斯旗下，工业状态监测领域领导者）
系列：3300 XL系列（高性能电涡流传感器系统）
核心功能：
非接触式测量转子与探头端面的动态间隙，实时监测振动、轴向位移、胀差、偏心等关键参数。
兼容Bently Nevada 3300/3500/4000系列监测系统及System 1软件，支持预测性维护与故障诊断。
适用于高温、高振动、强电磁干扰等严苛工业环境（如汽轮机、发电机、压缩机、齿轮箱等）。
二、型号分解与配置说明
Bently Nevada的型号编码规则通常包含以下关键参数信息。以330103-00-15-10-02-00为例：
字段含义取值（本型号）说明
330103基础型号330103表示3300 XL系列电涡流传感器套件，标准配置包含探头、延伸电缆、前置器。
00探头类型00标准型探头（非高温、非特殊材质），适用于常规工业环境。
15探头量程15mm测量范围0.25mm至15mm，适用于超大位移监测场景（如大型汽轮机胀差）。
10延伸电缆长度10英尺（约3.05米）短距离信号传输，适用于紧凑型设备或前置器就近安装场景。
02前置器类型02标准型前置器（非防爆、非特殊功能），支持模拟/数字信号输出。
00附加选项00无特殊配置（如校准证书、特殊包装等）。
三、系统组成与核心组件
330103-00-15-10-02-00为完整传感器套件，包含以下组件：
1.探头（Proximity Probe）
型号：3300 XL 15mm探头。
功能：
非接触式测量转子与探头端面的动态间隙，反映设备振动、位移等状态。
关键特性：
超大范围高精度测量：
量程：0.25mm至15mm，覆盖大型设备热膨胀、机械松动等极端位移场景。
分辨率：≤0.1μm（典型值），满足精密监测需求。
线性度：≤±1%全量程，确保数据准确性。
耐温设计：
标准型号：-35℃至+175℃（探头头部），适用于大多数工业环境。
抗振动干扰：
探头结构强化，适应高振动环境（振动幅度>500μm）。
Bently Nevada 330103-00-15-10-02-00 product details.This model is a high-performance suite of the 3300 XL Series eddy-current displacement sensor system.Similar to the previously mentioned 330103-00-10-50-02-00,it features enhanced range and extended cable length,making it suitable for industrial applications requiring ultra-large displacement monitoring and ultra-long-distance signal transmission(such as large steam turbines,generators,and equipment with long shafting).The following details are provided:
I.Product Overview
Model:330103-00-15-10-02-00
Brand:Bently Nevada(a Baker Hughes company,a leader in industrial condition monitoring)
Series:3300 XL Series(High-Performance Eddy-Current Sensor System)
Core Function:
Non-contact measurement of the dynamic clearance between the rotor and the probe tip,enabling real-time monitoring of key parameters such as vibration,axial displacement,differential expansion,and eccentricity.Compatible with the Bently Nevada 3300/3500/4000 series monitoring systems and System 1 software,it supports predictive maintenance and fault diagnosis.
It is suitable for harsh industrial environments(such as turbines,generators,compressors,and gearboxes)subject to high temperatures,high vibration,and strong electromagnetic interference.
II.Model Decomposition and Configuration Description
The Bently Nevada model coding scheme generally includes the following key parameters.Taking 330103-00-15-10-02-00 as an example:
Field Meaning Value(This Model)Description
330103 Basic Model 330103 represents the 3300 XL Series Eddy Current Sensor Kit.The standard configuration includes the probe,extension cable,and preamplifier.
00 Probe Type 00 Standard probe(non-high temperature,non-special material),suitable for general industrial environments.15 Probe Range:15mm.Measuring range:0.25mm to 15mm,suitable for monitoring extremely large displacements(such as differential expansion on large steam turbines).
10 Extension Cable Length:10 feet(approximately 3.05 meters).Short-distance signal transmission,suitable for compact equipment or when the proximity sensor is installed close to the sensor.
02 Sensor Type:02 Standard sensor(non-explosion-proof,non-special functions),supporting analog/digital signal output.
00 Additional Options:00.No special configurations(such as calibration certificates,special packaging,etc.).
III.System Composition and Core Components
330103-00-15-10-02-00 is a complete sensor kit,including the following components:
1.Proximity Probe
Model:3300 XL 15mm Probe.
Function:
Non-contact measurement of the dynamic clearance between the rotor and the probe end face,reflecting equipment vibration,displacement,and other conditions.
Key Features:
Ultra-Wide Range,High-Precision Measurement:
Measuring range:0.25mm to 15mm,covering extreme displacement scenarios such as thermal expansion and mechanical loosening of large equipment.
Resolution:≤0.1μm(typical),meeting precision monitoring needs.
Linearity:≤±1%full-scale,ensuring data accuracy.
Temperature-Resistant Design:
Standard models:-35°C to+175°C(probe head),suitable for most industrial environments.
Vibration Resistance:
The reinforced probe structure withstands high-vibration environments(vibration amplitude>500μm).
