描述
Bently Nevada 330180-X0-00产品详情解析
该型号属于3300 XL系列电涡流传感器系统的定制化配置，其中“X0”为可变参数位，代表不同的探头量程或功能选项，而“00”通常表示标准配置（如无独立延伸电缆）。以下为详细信息：
一、产品概述
型号：330180-X0-00
品牌：Bently Nevada（贝克休斯旗下，工业状态监测领域领导者）
系列：3300 XL系列（高性能电涡流传感器系统）
核心功能：
非接触式测量转子与探头端面的动态间隙，实时监测振动、轴向位移、胀差、偏心等关键参数。
兼容Bently Nevada 3300/3500/4000系列监测系统及System 1软件，支持数据采集、分析与故障诊断。
适用于高温、高振动、强电磁干扰的严苛工业环境（如电力、石化、冶金行业）。
定位：
可定制化传感器套件，根据用户需求调整探头量程、材料或输出类型，平衡性能与成本。
二、型号分解与配置说明
Bently Nevada的型号编码规则中，“X0”为关键变量位，代表不同的探头或配置选项。以下是常见组合及含义：
X0组合探头类型与量程典型应用场景备注
12-00标准型，量程0.25-12mm常规振动/位移监测（如汽轮机轴承振动）默认配置，兼容性广
25-00长量程型，量程0.25-25mm大型设备极端位移监测（如汽轮机胀差）需确认系统兼容性
50-00超长量程型，量程0.25-50mm特殊场景（如超大型压缩机轴向位移）定制化选项，需单独询价
HT-00高温型，量程0.25-12mm高温环境（如燃气轮机轴承监测）探头耐温可达260℃，需后缀标注
EX-00防爆型，量程0.25-12mm危险区域（如石化行业爆炸性气体环境）符合ATEX/IECEx认证
“00”后缀通常表示：
无独立延伸电缆：探头与前置器通过集成短电缆直接连接（长度<1米）。
标准输出：模拟信号（4-20mA或-24V至0V），无数字通信模块。
Bently Nevada 330180-X0-00 Product Details
This model number is a customized configuration for the 3300 XL Series Eddy Current Sensor System.”X0″is a variable parameter digit,representing different probe ranges or function options,while”00″generally indicates a standard configuration(e.g.,without a separate extension cable).The following details are provided:
I.Product Overview
Model:330180-X0-00
Brand:Bently Nevada(a Baker Hughes company,a leader in industrial condition monitoring)
Series:3300 XL Series(High-Performance Eddy Current Sensor System)
Core Functions:
Non-contact measurement of the dynamic clearance between the rotor and the probe tip,providing real-time monitoring of key parameters such as vibration,axial displacement,differential expansion,and eccentricity.
Compatible with the Bently Nevada 3300/3500/4000 Series Monitoring Systems and System 1 software,supporting data acquisition,analysis,and troubleshooting.Suitable for harsh industrial environments with high temperatures,high vibration,and strong electromagnetic interference(such as the power generation,petrochemical,and metallurgical industries).
Positioning:
Customizable sensor kits allow you to adjust probe range,material,or output type based on user needs,balancing performance and cost.
II.Model Decomposition and Configuration Instructions
In the Bently Nevada model numbering convention,”X0″is a key variable,representing different probes or configuration options.The following are common combinations and their meanings:
X0 Combination Probe Type and Range Typical Applications Notes
12-00 Standard,range 0.25-12mm General vibration/displacement monitoring(e.g.,turbine bearing vibration)Default configuration,wide compatibility
25-00 Long-range,range 0.25-25mm Extreme displacement monitoring of large equipment(e.g.,turbine differential expansion)System compatibility must be confirmed
50-00 Ultra-long-range,range 0.25-50mm Special applications(e.g.,axial displacement of ultra-large compressors)Custom options available,please inquire separately
HT-00 High-temperature,range 0.25-12mm High-temperature environments(e.g.,gas turbine bearing monitoring)Probe temperature resistance up to 260°C(suffix required)
EX-00 Explosion-proof,range 0.25-12mm Hazardous areas(e.g.,explosive gas atmospheres in the petrochemical industry)Compliant with ATEX/IECEx Certifications
The”00″suffix generally indicates:
No separate extension cable:The probe connects directly to the proximitor sensor via an integrated short cable(less than 1 meter in length).
Standard output:Analog signal(4-20mA or-24V to 0V),no digital communication module.
