描述
ABB 5SHY3545L0016(3BHB020720R0002)产品详情
产品概述
ABB 5SHY3545L0016，其完整模块号为3BHB020720R0002，是一款来自ABB公司（现为Hitachi Energy）的大功率IGBT/IGCT（绝缘栅双极型晶体管/集成门极换向晶闸管）模块。该模块属于高性能半导体器件，是高功率变流器和变频器中的核心组件。它作为高速电子开关，负责在电力电子电路中高效地转换和控制大电流和高电压的电能。
主要特性与规格
品牌：ABB Semiconductors(现为Hitachi Energy)
型号：5SHY3545L0016
完整模块号：3BHB020720R0002
产品类型：大功率IGBT/IGCT模块
功能：
电能转换：作为变流器、整流器和逆变器中的关键开关元件，用于实现交流到直流、直流到交流等电能转换。
高频开关：能够在高频率下进行开关操作，从而实现高效、精确的电力控制。
高功率密度：在一个紧凑的封装内集成半导体芯片和二极管，能够处理极大的电流和电压。
技术参数解析：
5SHY：代表ABB的IGBT模块系列。
3545：通常表示其电压和电流等级。例如，“35”可能代表3500V电压等级，而“45”可能代表其额定电流。
L0016：具体的子型号和配置代码。
产品优势：
高可靠性：专为严苛的工业应用设计，具备出色的热管理和抗短路能力。
高效率：能够显著降低电能转换过程中的损耗，提高系统效率。
应用领域
该大功率模块广泛应用于需要进行高功率电能转换和控制的工业领域：
工业变频器：在变频器中，用于驱动大型电机。
轨道交通：在高铁和地铁的牵引逆变器中。
电力传输：在高压直流输电（HVDC）和柔性交流输电（FACTS）系统中。
ABB Model:GBU72 3BHE055094R0002 Model:3BHE055094R0002 GBU72 Model:GBU72 Model:3BHE055094R0002 Model:3BHE031197R0001 Model:3BHB030310R0001 Model:73BHE055094R0002 GBU72 Model:73BHE055094R0002 Model:GBU72 Model:ABB PCS6000 PRODUCT FAMLIY ABB 5SHY4045L0006 3BHB030310R0001 3BHE039203R0101 GVC736CE101
ABB 5SHY3545L0016(3BHB020720R0002)Product Details
Product Overview
The ABB 5SHY3545L0016,with the full module number 3BHB020720R0002,is a high-power IGBT/IGCT(insulated-gate bipolar transistor/integrated gate-commutated thyristor)module from ABB(now Hitachi Energy).This module is a high-performance semiconductor device and a core component in high-power converters and inverters.It functions as a high-speed electronic switch,efficiently converting and controlling high current and high voltage electrical energy in power electronic circuits.
Key Features and Specifications
Brand:ABB Semiconductors(now Hitachi Energy)
Model:5SHY3545L0016
Full Module Number:3BHB020720R0002
Product Type:High-Power IGBT/IGCT Module
Function:
Power Conversion:Serves as a key switching element in converters,rectifiers,and inverters,enabling power conversion from AC to DC and DC to AC.
High-Frequency Switching:Capable of switching at high frequencies,it enables efficient and precise power control.
High Power Density:Integrates semiconductor chips and diodes in a compact package,capable of handling extremely high currents and voltages.
Technical Parameters Explanation:
5SHY:Represents ABB’s IGBT module series.
3545:Typically indicates its voltage and current ratings.For example,”35″might represent a voltage rating of 3500V,while”45″might represent its rated current.
L0016:Specific sub-model and configuration code.
Product Advantages:
High Reliability:Designed for demanding industrial applications,it offers excellent thermal management and short-circuit robustness.
High Efficiency:Significantly reduces losses during power conversion,improving system efficiency.
Applications
This high-power module is widely used in industrial applications requiring high-power power conversion and control:
Industrial Inverters:Used in inverters to drive large motors.
Rail Transit:Used in traction inverters for high-speed trains and subways.
Power Transmission:Used in High-Voltage Direct Current(HVDC)and Flexible Alternating Current Transmission(FACTS)systems.
