ABB GDD830 B105(3BHE022678R0105)产品详情
产品概述
ABB GDD830 B105，其完整物料号为3BHE022678R0105，是一款来自ABB公司的门极驱动单元或门极驱动板卡。该模块是ABB高功率变流器和传动系统中的一个关键电子组件。它的核心功能是为功率半导体器件（如IGBT、IGCT或晶闸管）提供精确、可靠的门极触发信号，以控制它们的开关动作。由于高压环境，该模块通常采用光纤通信，以确保控制电路与主功率电路之间的高压电气隔离，从而保证系统的安全与稳定。
主要特性与规格
品牌：ABB
型号：GDD830 B105
完整物料号：3BHE022678R0105
产品类型：门极驱动单元/光纤驱动板
兼容系统：专用于ABB的高功率变流器或传动系统，例如用于工业变频器、轨道交通牵引变流器或高压直流（HVDC）输电系统。
功能：
门极驱动：负责生成并放大控制信号，以驱动功率半导体器件的门极，使其按预定顺序导通和关断。
光纤通信：使用光纤接口进行信号传输，提供卓越的抗电磁干扰能力和高压隔离。
系统保护：集成了故障监测和保护功能，如过流或短路保护，以确保功率模块的安全运行。
产品状态：
作为高功率传动系统的核心组件，该板卡是设备维修和系统升级的重要备件，用于替换故障模块，以恢复驱动器的正常功能。
应用领域
该门极驱动单元作为ABB高功率变流系统的核心，广泛应用于：
工业传动：在冶金、采矿、石油天然气等行业中，用于驱动大型电机。
轨道交通：在高铁和地铁的牵引逆变器中。
电力系统：在高压直流（HVDC）输电和无功补偿（SVC）系统中。
系统维护：是维护和延长现有ABB高功率驱动器系统生命周期的核心部件。
ABB GDD830 B105(3BHE022678R0105)Product Details
Product Overview
The ABB GDD830 B105,with the full part number 3BHE022678R0105,is a gate driver unit or gate driver board from ABB.This module is a key electronic component in ABB’s high-power converters and drive systems.Its core function is to provide precise and reliable gate trigger signals to power semiconductor devices(such as IGBTs,IGCTs,or thyristors)to control their switching.Due to the high-voltage environment,this module typically uses fiber optic communication to ensure high-voltage electrical isolation between the control circuit and the main power circuit,thereby ensuring system safety and stability.
Key Features and Specifications
Brand:ABB
Model:GDD830 B105
Full Part Number:3BHE022678R0105
Product Type:Gate Driver Unit/Fiber Optic Driver Board
Compatible Systems:Designed for use in ABB’s high-power converters or drive systems,such as industrial inverters,rail traction converters,or high-voltage direct current(HVDC)transmission systems.
Function:
Gate Driver:Generates and amplifies control signals to drive the gates of power semiconductor devices,causing them to turn on and off in a predetermined sequence.
Fiber Optic Communication:Utilizes a fiber optic interface for signal transmission,providing excellent electromagnetic interference immunity and high-voltage isolation.
System Protection:Integrated fault monitoring and protection functions,such as overcurrent and short-circuit protection,ensure safe operation of the power module.
Product Status:
As a core component of high-power drive systems,this board is a crucial spare part for equipment repairs and system upgrades,replacing faulty modules to restore normal drive functionality.
Applications
This gate drive unit,the core of ABB’s high-power converter systems,is widely used in the following applications:
Industrial Drives:Driving large motors in industries such as metallurgy,mining,and oil and gas.
Rail Transit:In traction inverters for high-speed trains and subways.
Power Systems:In high-voltage direct current(HVDC)transmission and reactive power compensation(SVC)systems.
System Maintenance:A key component for maintaining and extending the lifecycle of existing ABB high-power drive systems.
