描述
一、产品定位与核心功能
模块类型
-基本单元/主控制器：集成CPU、通信接口及I/O扩展能力，支持AC31系统总线；
-安全等级：符合SafetyBridge系统标准，适用于紧急停止、安全门等安全相关应用。
核心功能
-控制能力：支持逻辑运算、数据采集及高速计数（频率达50kHz）；
-通信集成：内置以太网、RS-485接口，兼容Modbus、EtherCAT及ABB专有协议；
-扩展性：可通过CS31总线连接最多32个从站模块。
二、技术参数
|项目|参数/功能|
|电源输入|24V DC（允许波动±15%）|
|功耗|典型电流2A，峰值4A|
|存储容量|用户程序1MB+用户数据1MB（Flash+RAM）|
|I/O能力|24×DI（24V DC）、16×DO（继电器/晶体管）|
|物理特性|尺寸150×100×40mm，重量1.36kg|
|环境适应性|工作温度-20–60°C，湿度5–95%（非凝露）|
|防护等级|IP20|
三、应用场景
制造业
-机械臂控制、生产线自动化（如汽车装配、电子制造）；
-配合DSQC系列模块实现多轴协同。
能源与化工
-发电厂设备监控、石化管道阀门联动；
-冗余配置用于关键工艺的安全联锁。
1.Product positioning and core functions
Module Type
-Basic unit/main controller:Integrate CPU,communication interface and I/O expansion capabilities,and supports AC31 system bus;
-Safety Level:Comply with SafetyBridge system standards and is suitable for safety-related applications such as emergency stops and safety doors.
Core functions
-Control capability:Supports logical operations,data acquisition and high-speed counting(frequency up to 50kHz);
-Communication integration:built-in Ethernet and RS-485 interface,compatible with Modbus,EtherCAT and ABB proprietary protocols;
-Extensibility:Up to 32 slave modules can be connected through the CS31 bus.
2.Technical parameters
|Project|Parameters/Functions|
|Power input|24V DC(permitted fluctuation±15%)|
|Power consumption|Typical current 2A,peak 4A|
|Storage capacity|User program 1MB+User data 1MB(Flash+RAM)|
|I/O capability|24×DI(24V DC),16×DO(relay/transistor)|
|Physical Characteristics|Dimensions 150×100×40mm,weight 1.36kg|
|Environmental adaptability|Operating temperature-20–60°C,humidity 5–95%(non-condensing)|
|Protection level|IP20|
III.Application scenarios
Manufacturing
-robotic arm control,production line automation(such as automotive assembly,electronic manufacturing);
-Multi-axis coordination is achieved with DSQC series modules.
Energy and Chemical Industry
-Power plant equipment monitoring and petrochemical pipeline valve linkage;
-Redundant configuration for safety interlocks for critical processes
