描述
一、产品定位与核心功能
1.目标应用场景
接触器扩展：
与ABB AF系列、A系列接触器配合，增加辅助触点数量（如从2组触点扩展至4组或6组），满足复杂控制回路需求。
适用于电机启停控制、变频器启停信号传输等场景。
断路器状态反馈：
安装于ABB Tmax XT、Emax 2系列断路器侧面，提供分合闸状态信号，用于PLC、SCADA系统的实时监测。
继电器信号转换：
将主回路通断状态转换为低电压/小电流信号，驱动指示灯、报警器、中间继电器等负载。
2.核心功能
触点扩展：
提供1~4组独立触点（根据型号不同），每组包含1常开（NO）+1常闭（NC）触点，支持并联或串联使用。
信号隔离：
触点与主回路电气隔离，避免高压干扰对控制回路的影响，确保信号稳定性。
机械联锁：
通过机械联动机构与主开关设备（如接触器）同步动作，保证触点状态与主回路一致，防止误操作。
二、技术规格与性能参数
1.电气参数
触点容量：
额定电流：AC 250V/10A或DC 30V/5A（电阻性负载），兼容大多数控制回路负载。
短路耐受能力：10kA（1s），符合IEC 60947-5-1标准，确保短路故障时的安全性。
触点类型：
银合金触点：抗电弧、耐磨损，寿命>100万次操作。
触点材料：AgNi10（银镍10%），优化导电性与抗熔焊性能。
绝缘性能：
绝缘电阻：>100MΩ（500V DC），防止漏电或短路。
耐压强度：2kV/1min（工频耐压），适应工业环境电压波动。
2.机械参数
外壳材质：
阻燃PC+ABS合金，符合UL94 V-0防火标准，确保电气安全。
安装方式：
导轨安装：支持35mm DIN导轨，可快速集成到控制柜中。
螺钉固定：提供安装孔位，适用于嵌入式安装到设备面板。
防护等级：
IP20（基础版），防尘防水，适应室内环境；可选IP65防护罩用于室外或潮湿场景。
3.环境适应性
工作温度：-25℃~+70℃，适应极端温度环境（如钢铁厂、冷库）。
存储温度：-40℃~+85℃，确保运输与长期存储时的可靠性。
湿度范围：5%~95%RH（无凝露），兼容高湿度场景（如造纸、纺织行业）。
振动/冲击：
振动耐受：5~55Hz，1mm双振幅，符合IEC 60068-2-6标准。
冲击耐受：15g/11ms，适应运输或安装过程中的机械冲击。
三、产品特点与优势
1.高可靠性设计
双触点结构：每组触点采用双断点设计，提高分断能力与可靠性，减少电弧残留。
自清洁功能：触点动作时通过摩擦自清洁，去除氧化层或污垢，延长使用寿命。
2.模块化扩展
即插即用：与ABB主开关设备通过标准接口快速连接，无需额外接线或调试。
堆叠安装：支持多个辅助触点模块堆叠，最多可扩展至8组触点，满足大型控制系统需求。
3.智能化兼容（可选）
通信接口支持：部分型号集成RS-485接口或Modbus RTU协议，可将触点状态数据上传至PLC或SCADA系统，实现远程监控与故障诊断。
LED状态指示：
绿色（Power）：电源正常。
红色（Trip）：触点动作（如断路器分闸），需手动复位。
I.Product Positioning and Core Functions
1.Target Application Scenarios
Contactor Expansion:
Combined with ABB AF and A series contactors,it increases the number of auxiliary contacts(e.g.,from two to four or six groups)to meet the needs of complex control circuits.
It is suitable for scenarios such as motor start/stop control and inverter start/stop signal transmission.
Circuit Breaker Status Feedback:
Installed on the side of ABB Tmax XT and Emax 2 series circuit breakers,it provides open/close status signals for real-time monitoring in PLC and SCADA systems.
Relay Signal Conversion:
Converts the main circuit on/off status into low-voltage/low-current signals to drive loads such as indicator lights,alarms,and intermediate relays.
2.Core Functions
Contact Expansion:
Provides one to four independent contact groups(depending on the model).Each group consists of one normally open(NO)and one normally closed(NC)contact,supporting parallel or series operation.Signal Isolation:
The contacts are electrically isolated from the main circuit,preventing high-voltage interference from affecting the control circuit and ensuring signal stability.
Mechanical Interlock:
A mechanical linkage mechanism synchronizes the operation with the main switching device(such as a contactor)to ensure that the contact state is consistent with the main circuit,preventing erroneous operation.
II.Technical Specifications and Performance Parameters
1.Electrical Parameters
Contact Capacity:
Rated Current:AC 250V/10A or DC 30V/5A(resistive load),compatible with most control circuit loads.
Short-Circuit Withstand Capacity:10kA(1s),compliant with IEC 60947-5-1,ensuring safety during short-circuit faults.
Contact Type:
Silver alloy contacts:arc-resistant and wear-resistant,with a lifespan of>1 million operations.
Contact Material:AgNi10(silver nickel 10%),optimized for conductivity and resistance to welding.Insulation Performance:
Insulation resistance:>100MΩ(500V DC),preventing leakage and short circuits.
Dielectric strength:2kV/1min(power frequency withstand voltage),adaptable to voltage fluctuations in industrial environments.
2.Mechanical Parameters
Casing Material:
Flame-retardant PC+ABS alloy,meeting UL94 V-0 fire protection standards,ensuring electrical safety.
Mounting Method:
Din-rail mounting:Supports 35mm DIN rails for quick integration into control cabinets.
Screw fixing:Provides mounting holes for flush mounting on equipment panels.
Protection Rating:
IP20(basic version),dustproof and waterproof,suitable for indoor environments;optional IP65 protective cover for outdoor or humid environments.
3.Environmental Adaptability
Operating Temperature:-25°C to+70°C,suitable for extreme temperature environments(such as steel mills and cold storage).
Storage Temperature:-40°C to+85°C,ensuring reliability during transportation and long-term storage.Humidity Range:5%-95%RH(non-condensing),compatible with high-humidity environments(such as the papermaking and textile industries).
Vibration/Shock:
Vibration resistance:5-55Hz,1mm double amplitude,compliant with IEC 60068-2-6.
Shock resistance:15g/11ms,suitable for mechanical shock during transportation and installation.
III.Product Features and Advantages
1.High-Reliability Design
Dual Contact Structure:Each contact set utilizes a dual-break design,improving breaking capacity and reliability while reducing arc residue.
Self-Cleaning Function:Contacts clean themselves through friction during operation,removing oxide layers and dirt,extending service life.
2.Modular Expansion
Plug-and-Play:Quickly connects to ABB main switchgear via standard interfaces,requiring no additional wiring or commissioning.
Stackable Installation:Multiple auxiliary contact modules can be stacked together,expanding the system to up to eight contact groups,meeting the needs of large-scale control systems.3.Intelligent Compatibility(Optional)
Communication Interface Support:Some models integrate RS-485 or Modbus RTU protocols,enabling contact status data to be uploaded to a PLC or SCADA system for remote monitoring and fault diagnosis.
LED Status Indicators:
Green(Power):Power is normal.
Red(Trip):Contacts are actuated(e.g.,circuit breaker tripped),requiring manual reset.
