描述
一、产品定位与核心优势
1.目标应用场景
工业自动化控制：
生产线状态监测：采集传感器信号（如限位开关、压力开关、温度开关），实时反馈设备运行状态（如“运行/停止”“正常/故障”）。
安全联锁系统：监测急停按钮、安全光幕、门锁开关等安全信号，触发设备停机或报警，确保人员与设备安全。
过程控制系统：
化工/制药行业：采集液位开关、流量开关、pH值传感器的数字信号，实现批次控制与工艺联锁。
水处理系统：监测水泵状态、阀门位置、水质超标等信号，优化供水调度与节能运行。
能源管理系统：
电力监控：采集断路器分合闸状态、电能表脉冲信号，实现用电量统计与负荷分析。
楼宇自动化（BAS）：监测空调、照明、电梯的运行状态，支持能耗监测与智能调度。
2.核心优势
高抗干扰能力：
光电隔离技术：输入通道与模块内部电路采用2000V DC隔离，有效抑制工业现场的电磁干扰（EMI）与静电放电（ESD）。
滤波算法：内置数字滤波器，消除信号抖动与毛刺，确保状态检测的稳定性。
宽电压输入范围：
支持DC 24V（±30%）或AC 110V/220V（±20%）输入，兼容多种传感器与控制回路，减少电源适配器的使用。
快速响应特性：
信号响应时间：<1ms，满足高速运动控制（如包装机、印刷机）与实时安全联锁的需求。
二、硬件规格与性能
1.电气参数
输入通道：
通道数量：8路数字量输入，可独立配置为NPN或PNP型传感器输入。
输入电压范围：
DC输入：10V~36V DC（典型值24V DC），支持漏型（Sink）或源型（Source）接线。
AC输入：85V~265V AC（典型值110V/220V AC），适应不同国家的电网标准。
输入电流：
DC输入：<5mA（24V DC时），降低传感器供电负荷。
AC输入：<10mA（220V AC时），减少控制回路能耗。
输出特性：
状态指示：每路输入通道配备LED指示灯，实时显示信号状态（ON/OFF），便于现场调试与故障排查。
逻辑电平：输入信号经模块处理后，输出TTL兼容电平（0V/5V），可直接接入PLC或微控制器。
2.机械参数
外壳材质：阻燃PC+ABS合金，符合UL94 V-0防火标准，确保电气安全。
安装方式：
导轨安装：支持35mm DIN导轨，可快速集成到控制柜或配电箱中。
面板安装：提供安装孔位，适用于嵌入式安装到设备面板。
防护等级****：IP20（基础版）或IP65（加装防护罩后），防尘防水，适应室内/室外环境。
3.环境适应性
工作温度：-20℃~+60℃，满足常规工业环境需求；可选宽温版（-40℃~+85℃），适应极寒或高温场景。
存储温度：-40℃~+85℃，确保运输与长期存储时的可靠性。
湿度范围：5%~95%RH（无凝露），适应潮湿环境（如食品加工、造纸行业）。
三、软件功能与配置
1.通信协议
支持多种总线协议：
Modbus RTU：通过RS-485接口实现主从通信，兼容PLC、HMI、SCADA系统。
CANopen：支持CiA 301标准，适用于分布式控制系统与运动控制网络。
Profibus-DP：可选配Profibus-DP模块，集成到西门子、ABB等主流PLC系统。
I.Product Positioning and Core Advantages
1.Target Application Scenarios
Industrial Automation Control:
Production Line Status Monitoring:Collects sensor signals(such as limit switches,pressure switches,and temperature switches)to provide real-time feedback on equipment operating status(e.g.,”Running/Stopped,””Normal/Faulted”).
Safety Interlock System:Monitors safety signals such as emergency stop buttons,safety light curtains,and door lock switches,triggering equipment shutdowns or alarms to ensure personnel and equipment safety.
Process Control System:
Chemical/Pharmaceutical Industry:Collects digital signals from level switches,flow switches,and pH sensors to implement batch control and process interlocks.
Water Treatment System:Monitors pump status,valve position,and water quality violations to optimize water supply scheduling and energy-saving operations.
Energy Management System:
Power Monitoring:Collects circuit breaker open/close status and energy meter pulse signals to implement power consumption statistics and load analysis.
Building Automation System(BAS):Monitors the operating status of air conditioners,lighting,and elevators,supporting energy consumption monitoring and intelligent scheduling.2.Core Advantages
High Anti-interference Capability:
Optoelectronic Isolation Technology:Input channels are isolated from the module’s internal circuitry with 2000V DC,effectively suppressing electromagnetic interference(EMI)and electrostatic discharge(ESD)in industrial environments.
Filtering Algorithm:A built-in digital filter eliminates signal jitter and glitches,ensuring stable status detection.
Wide Voltage Input Range:
Supports DC 24V(±30%)or AC 110V/220V(±20%)inputs,compatible with a variety of sensors and control circuits,reducing the need for power adapters.
Fast Response:
Signal response time:<1ms,meeting the requirements of high-speed motion control(such as packaging and printing machines)and real-time safety interlocks.
II.Hardware Specifications and Performance
1.Electrical Parameters
Input Channels:
Number of Channels:8 digital inputs,independently configurable as NPN or PNP sensor inputs.Input Voltage Range:
DC Input:10V~36V DC(typical 24V DC),supports sink or source wiring.
AC Input:85V~265V AC(typical 110V/220V AC),adaptable to power grid standards in different countries.
Input Current:
DC Input:<5mA(at 24V DC),reducing sensor power supply load.
AC Input:<10mA(at 220V AC),reducing control circuit energy consumption.
Output Characteristics:
Status Indicator:Each input channel is equipped with an LED indicator,displaying the signal status(ON/OFF)in real time,facilitating on-site commissioning and troubleshooting.
Logic Level:After input signal processing,the module outputs TTL-compatible levels(0V/5V),suitable for direct connection to a PLC or microcontroller.
2.Mechanical Parameters
Case Material:Flame-retardant PC+ABS alloy,meeting UL94 V-0 fire protection standards,ensuring electrical safety.Mounting Methods:
Din-Rail Mounting:Supports 35mm DIN rails for quick integration into control cabinets or distribution boxes.
Panel Mounting:Provides mounting holes for flush-mount installation on equipment panels.
Protection Rating****:IP20(basic version)or IP65(with protective cover installed),dustproof and waterproof,suitable for indoor and outdoor environments.
3.Environmental Adaptability
Operating Temperature:-20°C to+60°C,meeting the requirements of conventional industrial environments;an optional wide-temperature version(-40°C to+85°C)is available for extreme cold and high temperatures.
Storage Temperature:-40°C to+85°C,ensuring reliability during transportation and long-term storage.
Humidity Range:5%to 95%RH(non-condensing),suitable for humid environments(such as food processing and papermaking).III.Software Features and Configuration
1.Communication Protocols
Supports multiple bus protocols:
Modbus RTU:Enables master-slave communication via the RS-485 interface,compatible with PLCs,HMIs,and SCADA systems.
CANopen:Supports the CiA 301 standard and is suitable for distributed control systems and motion control networks.
Profibus-DP:An optional Profibus-DP module is available for integration into mainstream PLC systems such as Siemens and ABB.
