描述
1.产品定位与核心功能
1.1应用场景
汽轮机/发电机监测：
在核电站、火电厂中，实时监测转子轴向位移、径向振动，防止动静部件摩擦、转子不平衡等故障，保障机组安全运行。
通常与3500系列监测系统配合使用，通过4-20mA或Modbus信号将数据传输至DCS/PLC系统，实现报警联锁控制。
压缩机/风机监测：
在石油化工、天然气输送领域，监测压缩机转子振动，结合频谱分析诊断轴承磨损、齿轮故障，优化维护计划。
支持Bently Nevada的System 1软件进行振动趋势分析与故障预警。
水轮机/泵监测：
在水电站、市政供水系统中，测量水轮机主轴振动，防止气蚀、叶片断裂等故障，延长设备寿命。
1.2技术亮点
高精度电涡流传感技术：
采用电涡流原理，非接触式测量转子与探头间隙，分辨率可达0.1μm，适用于高速旋转机械（转速＞3000rpm）的微小振动监测。
宽温度适应性：
工作温度范围-50℃至+175℃（探头头部），耐受工业现场高温/低温环境，确保传感器稳定性。
抗干扰能力强：
电磁兼容性（EMC）符合IEC 61000-4-2/3/4/5/6标准，抵抗静电放电、电快速瞬变、浪涌等干扰，保障信号可靠性。
模块化设计：
与Bently Nevada 3300/3500系列前置器、延伸电缆无缝兼容，支持热插拔更换，减少停机维护时间。
2.技术规格与详细参数
2.1基础参数
参数规格
型号100472-012
制造商ABB Bently Nevada（现属Baker Hughes）
系列3300系列电涡流探头
测量类型位移/振动传感器探头
探头直径8mm（标准工业尺寸，适用于大多数旋转机械）
量程范围0-2.54mm（0-100mils）（典型值，实际量程需根据前置器型号调整）
线性范围±0.5mm至±1.25mm（具体取决于前置器配置）
灵敏度8mV/μm（典型值）（输出电压与间隙变化成正比）
温度范围探头头部：-50℃至+175℃
探头线缆：-40℃至+120℃
防护等级IP68（探头头部，防尘防水）
线缆：IP67（防浸水）
防爆认证可选：
-ATEX Zone 0/1/2（Ex ia/ib/nA）
-IECEx
1.Product positioning and core functions
1.1 Application scenarios
Steam turbine/generator monitoring:
In nuclear power plants and thermal power plants,real-time monitoring of rotor axial displacement and radial vibration can be performed to prevent faults such as friction between moving and static parts and rotor imbalance,and ensure safe operation of the unit.
Usually used in conjunction with the 3500 series monitoring system,data is transmitted to the DCS/PLC system through 4-20mA or Modbus signals to achieve alarm interlock control.
Compressor/fan monitoring:
In the fields of petrochemicals and natural gas transportation,compressor rotor vibration is monitored,and bearing wear and gear failure are diagnosed by combining spectrum analysis to optimize maintenance plans.
Support Bently Nevada’s System 1 software for vibration trend analysis and fault warning.
Turbine/pump monitoring:
In hydropower stations and municipal water supply systems,turbine main shaft vibration is measured to prevent faults such as cavitation and blade breakage,and extend equipment life.
1.2 Technical highlights
High-precision eddy current sensing technology:
Using the eddy current principle,non-contact measurement of the gap between the rotor and the probe,the resolution can reach 0.1μm,which is suitable for monitoring the tiny vibration of high-speed rotating machinery(speed>3000rpm).
Wide temperature adaptability:
The operating temperature range is-50℃to+175℃(probe head),which can withstand high/low temperature environments in industrial sites to ensure sensor stability.
Strong anti-interference ability:
Electromagnetic compatibility(EMC)complies with IEC 61000-4-2/3/4/5/6 standards,resists interference such as electrostatic discharge,electrical fast transients,surges,etc.,and ensures signal reliability.
Modular design:
Seamlessly compatible with Bently Nevada 3300/3500 series preamplifiers and extension cables,supports hot-swap replacement,and reduces downtime maintenance time.
2.Technical Specifications and Detailed Parameters
2.1 Basic Parameters
Parameters Specifications
Model 100472-012
Manufacturer ABB Bently Nevada(now Baker Hughes)
Series 3300 Series Eddy Current Probes
Measurement Type Displacement/Vibration Sensor Probe
Probe Diameter 8mm(Standard Industrial Size,Suitable for Most Rotating Machinery)
Range 0-2.54mm(0-100mils)(Typical,Actual Range Needs to Be Adjusted According to the Proximitor Model)
Linear Range±0.5mm to±1.25mm(Depending on the Proximitor Configuration)
Sensitivity 8mV/μm(Typical)(Output Voltage Proportional to Gap Change)
Temperature Range Probe Head:-50℃to+175℃
Probe Cable:-40℃to+120℃
Protection Rating IP68(Probe Head,Dustproof and Waterproof)
Cable:IP67(Waterproof)
Explosion-proof Certification Optional:
-ATEX Zone 0/1/2(Ex ia/ib/nA)
-IECEx
