ABB 100472-012产品详情解析
ABB 100472-012是ABB集团推出的一款高性能振动传感器，属于其状态监测与预测性维护解决方案的核心组件之一。该产品通常为单轴或三轴压电式加速度传感器（IEPE类型），专为工业旋转机械（如电机、泵、风机、压缩机、汽轮机等）的振动监测设计，具备高精度、宽频响应和强环境适应性，广泛应用于电力、石油天然气、化工、冶金、轨道交通等行业。以下从功能特性、技术参数、应用场景及优势特点等方面进行详细说明：
一、产品概述
型号：100472-012
类别：
压电式加速度传感器（IEPE类型）：基于压电陶瓷材料的压电效应，将机械振动转换为电荷信号，内置信号调理电路（IEPE），输出低阻抗电压信号，适用于动态振动测量。
可选配置：单轴或三轴测量（具体需确认型号变体，如100472-012-01为单轴，100472-012-03为三轴）。
核心定位：
实时监测机械设备的振动加速度、速度或位移，为设备状态评估、故障诊断及预测性维护提供关键数据。
可与ABB的800xA Condition Monitoring系统、ABB Ability™状态监测服务或第三方数据采集系统（DAQ）无缝集成。
二、核心功能模块
振动信号检测
检测原理：
压电陶瓷材料在受到机械振动时产生电荷，内置IEPE电路将电荷信号转换为电压信号（如±5V或±10V），便于长距离传输和抗干扰。
检测参数：
加速度：测量振动加速度峰值、有效值（RMS）或频谱，单位为m/s²或g（1g=9.81 m/s²）。
速度/位移：通过外接积分器或内置电路将加速度信号转换为速度（mm/s）或位移（μm），用于评估振动严重程度。
多频段监测
频率响应：
典型带宽：0.5Hz至10kHz（部分型号可扩展至20kHz），覆盖低频（如不平衡、不对中）到高频（如轴承故障、齿轮啮合）振动。
动态范围：
高信噪比（SNR），可捕捉微弱振动信号（如早期轴承缺陷），量程可选±10g至±500g（依型号配置）。
ABB 100472-012 Product Details
The ABB 100472-012 is a high-performance vibration sensor launched by ABB,a core component of its Condition Monitoring and Predictive Maintenance solutions.This product is typically a uniaxial or triaxial piezoelectric accelerometer(IEPE type),designed specifically for vibration monitoring of industrial rotating machinery(such as motors,pumps,fans,compressors,and steam turbines).Featuring high accuracy,wide-band response,and strong environmental adaptability,it is widely used in industries such as power,oil and gas,chemicals,metallurgy,and rail transportation.The following provides a detailed description of its functional characteristics,technical parameters,application scenarios,and advantages:
I.Product Overview
Model:100472-012
Category:
Piezoelectric accelerometer(IEPE type):Based on the piezoelectric effect of piezoelectric ceramic materials,it converts mechanical vibration into a charge signal.With built-in signal conditioning circuitry(IEPE),it outputs a low-impedance voltage signal,making it suitable for dynamic vibration measurement.Available configurations:Single-axis or tri-axis measurement(please confirm model variant,e.g.,100472-012-01 for single-axis,100472-012-03 for tri-axis).
Core Positioning:
Real-time monitoring of vibration acceleration,velocity,or displacement of mechanical equipment,providing critical data for equipment condition assessment,fault diagnosis,and predictive maintenance.
Seamlessly integrates with ABB’s 800xA Condition Monitoring system,ABB Ability™Condition Monitoring Services,or third-party data acquisition systems(DAQ).
II.Core Functional Modules
Vibration Signal Detection
Detection Principle:
Piezoelectric ceramic materials generate an electric charge when subjected to mechanical vibration.The built-in IEPE circuit converts the charge signal into a voltage signal(e.g.,±5V or±10V),facilitating long-distance transmission and resisting interference.
Detection Parameters:
Acceleration:Measures peak value,effective value(RMS),or frequency spectrum of vibration acceleration in m/s²or g(1g=9.81 m/s²).Velocity/Displacement:Acceleration signals are converted to velocity(mm/s)or displacement(μm)via an external integrator or internal circuitry for vibration severity assessment.
Multi-band Monitoring
Frequency Response:
Typical bandwidth:0.5Hz to 10kHz(extendable to 20kHz on some models),covering low-frequency vibrations(such as imbalance and misalignment)to high-frequency vibrations(such as bearing faults and gear meshing).
Dynamic Range:
High signal-to-noise ratio(SNR)enables detection of weak vibration signals(such as early-stage bearing defects).The measurement range is selectable from±10g to±500g(depending on the model configuration).
