ABB 191921-T06产品详情解析
（高精度振动/速度传感器，适用于工业设备状态监测与预测性维护）
一、产品概述
型号：191921-T06
品牌：ABB（全球工业自动化与电力技术领导者）
类型：工业级振动/速度传感器（集成加速度与速度测量功能，支持宽频带监测）
核心定位：
专为旋转机械（如电机、泵、风机、压缩机、齿轮箱）的振动分析、故障诊断与健康管理设计。
适用于电力、石油天然气、化工、冶金、造纸、水处理等行业的设备状态监测系统。
兼容ABB 800xA、System 800、Advant OCS等控制系统，以及第三方监测平台（如PRONOSTIA、PRÜFTECHNIK）。
二、产品组成与核心组件
191921-T06为一体化传感器，集成以下功能模块：
1.传感器本体
测量类型：
加速度测量：0.5Hz至10kHz频带，适用于冲击、高频振动监测（如轴承故障、齿轮磨损）。
速度测量：10Hz至1kHz频带，适用于低频振动监测（如不平衡、不对中、基础松动）。
输出信号：
双通道独立输出：
通道1：加速度（4-20mA或0-10V，可配置）。
通道2：速度（4-20mA或0-10V，可配置）。
数字接口：RS485（Modbus RTU协议），支持多传感器组网与远程配置。
2.防护与安装结构
外壳材质：
不锈钢316L（防腐蚀、耐高温，适用于海洋平台、化工车间等恶劣环境）。
防护等级：
IP67（防尘防水，可短期浸没，适应户外或潮湿环境）。
安装方式：
M10螺纹安装：直接固定于设备表面，支持垂直/水平/倾斜安装。
磁吸式底座（可选）：快速部署，适用于临时监测或测试场景。
ABB 191921-T06 Product Details
(High-precision vibration/velocity sensor for industrial equipment condition monitoring and predictive maintenance)
I.Product Overview
Model:191921-T06
Brand:ABB(a global leader in industrial automation and power technology)
Type:Industrial-grade vibration/velocity sensor(integrated acceleration and velocity measurement functions,supporting wideband monitoring)
Core Positioning:
Designed for vibration analysis,fault diagnosis,and health management of rotating machinery(such as motors,pumps,fans,compressors,and gearboxes).
Suitable for equipment condition monitoring systems in industries such as power,oil and gas,chemicals,metallurgy,papermaking,and water treatment.
Compatible with control systems such as ABB 800xA,System 800,and Advant OCS,as well as third-party monitoring platforms(such as PRONOSTIA and PRÜFTECHNIK).II.Product Components and Core Components
The 191921-T06 is an integrated sensor with the following functional modules:
1.Sensor Body
Measurement Type:
Acceleration Measurement:0.5Hz to 10kHz frequency band,suitable for shock and high-frequency vibration monitoring(such as bearing failures and gear wear).
Velocity Measurement:10Hz to 1kHz frequency band,suitable for low-frequency vibration monitoring(such as imbalance,misalignment,and foundation looseness).
Output Signal:
Dual-channel independent output:
Channel 1:Acceleration(4-20mA or 0-10V,configurable).
Channel 2:Velocity(4-20mA or 0-10V,configurable).
Digital Interface:RS485(Modbus RTU protocol),supports multi-sensor networking and remote configuration.
2.Protection and Mounting Structure
Casing Material:
316L stainless steel(corrosion-resistant and high-temperature resistant,suitable for harsh environments such as offshore platforms and chemical plants).Protection Rating:
IP67(dustproof and waterproof,suitable for short-term immersion,suitable for outdoor and humid environments).
Mounting Method:
M10 threaded mount:Directly attaches to the device surface,supporting vertical,horizontal,and tilted mounting.
Optional magnetic base:Quickly deploys,ideal for temporary monitoring or testing scenarios.
