描述
主要产品详情及功能
通信网关：其主要功能是充当各种工业通信协议和设备之间的转换器和桥梁。这使得不同类型的设备（可能来自不同的制造商或使用不同的通信标准）能够在集成自动化系统中交换数据并协同工作。
多协议支持：1TGE120021R0010旨在支持一系列广泛使用的工业通信协议，包括：
Modbus(RTU/TCP)：用于与各种工业设备进行串行和基于以太网的通信。
PROFINET IO：用于工厂自动化中基于以太网的实时通信。
EtherNet/IP：另一种流行的工业以太网协议，尤其适用于罗克韦尔自动化系统。
这种多协议功能确保了高兼容性和灵活地集成到各种工业网络中。
信号映射：信号映射是一项关键功能。它在智能电子设备(IED)（例如保护和控制继电器）与更高级别的系统（例如网络控制中心(NCC)或分布式控制系统(DCS)）之间传输控制和监控信息。
实时数据传输：该网关支持高速数据传输和实时通信，这对于需要快速响应时间的应用至关重要，例如生产监控、数据采集和过程控制。
系统协调：它负责管理命令授权的动态分配并监控通信，确保整个系统的协调运行。
OPC支持：该模块支持OPC（过程控制的OLE）数据访问(DA)和报警与事件(AE)接口。这使得第三方OPC客户端可以更轻松地访问所连接设备的数据和报警信息。
硬件性能：它采用强大的工业嵌入式硬件设计，确保在严苛的工业环境中稳定可靠地运行。
灵活性和可扩展性：
模块化设计：易于集成到现有系统中，并支持快速部署。
DIN导轨安装：支持标准DIN导轨安装，可快速简便地进行物理设置。
可选I/O扩展：可支持各种I/O扩展选项，例如ASI和Profibus平台，以满足不同系统规模的需求。
诊断和维护：提供详细的诊断信息和状态指示灯(LED)，方便故障排除，降低维护复杂性。
紧凑尺寸：通常尺寸约为160毫米（宽）x 140毫米（高）x 250毫米（深）。
通用规格
制造商：ABB
系列：ABB MLink
类型：通信网关
输入电源：24 V DC
功耗：通常小于5W
工作温度：-20°C至60°C
存储温度：-40°C至85°C
湿度：5%至95%（无凝露）
重量：约0.5千克（某些来源称其重量高达2.974千克，可能取决于具体型号或包装）。
典型应用
ABB 1TGE120021R0010广泛应用于各行各业，以实现集成高效的自动化：
工业自动化：在自动化生产线、物料搬运和过程控制中连接PLC、HMI、驱动器和其他控制设备。
变电站：用于保护继电器(IED)和中央控制系统之间的通信和信号映射。
楼宇自动化：集成各种楼宇系统，实现集中监控。
电力行业：在发电和配电领域进行数据交换和系统协调。
制造业：增强不同制造流程（例如机床、纺织、包装、印刷、烟草、塑料、橡胶、起重、工程机械、物流、电梯、电子制造）中不同机器和系统之间的互操作性和数据流。
Key Product Details and Functions
Communication Gateway:Its primary function is to act as a translator and bridge between various industrial communication protocols and devices.This allows different types of equipment,potentially from different manufacturers or using different communication standards,to exchange data and work together in an integrated automation system.
Multi-Protocol Support:The 1TGE120021R0010 is designed to support a range of widely used industrial communication protocols,including:
Modbus(RTU/TCP):For serial and Ethernet-based communication with a vast array of industrial devices.
PROFINET IO:For real-time Ethernet-based communication in factory automation.
EtherNet/IP:Another prevalent industrial Ethernet protocol,especially common with Rockwell Automation systems.
This multi-protocol capability ensures high compatibility and flexible integration into diverse industrial networks.
Signal Mapping:A key function is signal mapping.It transfers control and monitoring information between intelligent electronic devices(IEDs)–such as protection and control relays–and higher-level systems like Network Control Centers(NCCs)or Distributed Control Systems(DCS).
Real-time Data Transmission:The gateway supports high-speed data transmission and real-time communication,which is essential for applications requiring fast response times,such as production monitoring,data acquisition,and process control.
System Coordination:It’s responsible for managing the dynamic distribution of command authorization and supervising communication,ensuring coordinated operation across the system.
OPC Support:The module supports OPC(OLE for Process Control)Data Access(DA)and Alarm&Event(AE)interfaces.This makes it easier for third-party OPC clients to access data and alarms from the connected devices.
Hardware Performance:It features a powerful industrial embedded hardware design,ensuring robust and reliable operation in demanding industrial environments.
Flexibility and Expandability:
Modular Design:Facilitates easy integration into existing systems and allows for rapid deployment.
DIN Rail Mounting:Supports standard DIN rail installation for quick and straightforward physical setup.
Optional I/O Expansion:Can support various I/O expansion options,like ASI and Profibus platforms,to meet the needs of different system sizes.
Diagnostics and Maintenance:Provides detailed diagnostic information and status indicators(LEDs)for easy troubleshooting,reducing maintenance complexity.
Compact Dimensions:Typically has dimensions around 160 mm(width)x 140 mm(height)x 250 mm(depth).
General Specifications
Manufacturer:ABB
Series:ABB MLink
Type:Communication Gateway
Input Power:24 V DC
Power Consumption:Typically less than 5W
Operating Temperature:-20°C to 60°C
Storage Temperature:-40°C to 85°C
Humidity:5%to 95%(non-condensing)
Weight:Approximately 0.5 kg(some sources indicate up to 2.974 kg,likely depending on specific variant or packaging).
Typical Applications
The ABB 1TGE120021R0010 is used in a wide array of industrial sectors to facilitate integrated and efficient automation:
Industrial Automation:Connecting PLCs,HMIs,drives,and other control devices in automated production lines,material handling,and process control.
Utility Substations:For communication and signal mapping between protection relays(IEDs)and central control systems.
Building Automation:Integrating various building systems for centralized monitoring and control.
Power Industry:In power generation and distribution for data exchange and system coordination.
Manufacturing:Enhancing interoperability and data flow across different machines and systems in diverse manufacturing processes(e.g.,machine tools,textile,packaging,printing,tobacco,plastic,rubber,lifting,engineering machinery,logistics,elevators,electronic manufacturing).
