一、产品概述与核心功能
模块类型
-二进制输出模块：将数字信号转换为二进制输出（高/低电平），驱动执行器或继电器；
-集成保护功能：过热、过载、短路保护，保障系统安全。
核心功能
-信号转换：支持16或32路数字输入通道，每通道独立控制二进制输出；
-通信扩展：集成以太网、RS485接口，兼容Modbus、PROFIBUS协议；
-灵活配置：支持编程设置输出逻辑、响应时间及通道组合。
二、技术参数
|项目|参数/功能|
|型号|216AB61（扩展型号含HESG系列）|
|输入电压|20–30V DC（部分型号支持9–36V宽范围）|
|输出规格|115–230V AC，额定电流6A|
|精度与功耗|转换精度±0.5%，功耗<10W|
|物理特性|重量0.351kg，尺寸100×65×25mm|
|环境适应性|工作温度-10–+55°C，防护等级IP20|
|认证|IEC 60950-1、UL 508、CE|
三、应用场景
工业自动化
-生产线设备控制（如传送带、机械臂）；
-电力系统开关状态监控。
能源与交通
-变电站断路器联动、轨道交通信号控制；
-太阳能逆变器、风力发电机的逻辑输出。
其他领域
-医疗设备电源管理、楼宇自动化系统。
1.Product overview and core functions
Module Type
-Binary output module:converts digital signals into binary output(high/low level),drives actuators or relays;
-Integrated protection functions:overheating,overloading,short circuit protection to ensure system safety.
Core functions
-Signal conversion:supports 16 or 32 digital input channels,and each channel independently controls binary output;
-Communication extension:Integrate Ethernet and RS485 interfaces,compatible with Modbus and PROFIBUS protocols;
-Flexible configuration:supports programming setting output logic,response time and channel combination.
2.Technical parameters
|Project|Parameters/Functions|
|Model|216AB61(Extended model includes HESG series)|
|Input voltage|20–30V DC(some models support wide range of 9–36V)|
|Output Specifications|115–230V AC,rated current 6A|
|Accuracy and power consumption|Conversion accuracy±0.5%,power consumption<10W|
|Physical Characteristics|Weight 0.351kg,dimensions 100×65×25mm|
|Environmental adaptability|Operating temperature-10–+55°C,protection level IP20|
|Certification|IEC 60950-1,UL 508,CE|
III.Application scenarios
Industrial automation
-Production line equipment control(such as conveyor belts,robotic arms);
-Power system switch status monitoring.
Energy and Transportation
-Substation circuit breaker linkage and rail transit signal control;
-Logical output of solar inverters and wind turbines.
Other fields
-Medical equipment power management,building automation system.
