描述
ABB 216EA62有多种类型，较为常见的是作为ABB IRC5机器人控制系统的标准FlexPendant示教器，以及作为ABB REG216数字发电机保护模块中的模拟输入单元，以下是这两种类型的产品详情：
ABB IRC5机器人控制系统的FlexPendant示教器
基本信息：型号为216EA62-1，部件号为MRB178066R1E。屏幕为7-8英寸彩色TFT液晶显示屏，分辨率为800×480像素，采用电阻式触摸屏。通过一根标准长度约6-8米的螺旋电缆连接到IRC5控制柜的示教器接口，支持热插拔。内置可充电锂电池，用于在断开连接时保持时间和设置。
功能特点：集成了高分辨率彩色触摸屏、急停按钮、使能装置、摇杆、功能按键于一体。操作员可手持它在机器人周围安全移动，进行机器人编程、参数设置、手动点动、运行监控、故障诊断等操作。支持多语言，图形化菜单直观易用。
技术参数：工作温度为0°C至45°C，防护等级为IP65，符合IEC 60204-1、ISO 10218-1、CE、UL等标准。
ABB REG216数字发电机保护模块的模拟输入单元
基本信息：属于ABB REG216数字发电机保护模块的一部分。
功能特点：具有24个输入通道，可同时采样，每组6个。
技术参数：采样频率为600（720）Hz，电源频率为50（60）Hz，所需空间为两个机架分区。
The ABB 216EA62 comes in several types.The most common use is as a standard FlexPendant teach pendant for the ABB IRC5 robot control system and as an analog input unit in the ABB REG216 digital generator protection module.Product details for both types are as follows:
ABB FlexPendant teach pendant for the IRC5 robot control system
Basic Information:Model 216EA62-1,part number MRB178066R1E.The screen is a 7-8 inch color TFT LCD with a resolution of 800×480 pixels and a resistive touchscreen.It connects to the teach pendant interface on the IRC5 control cabinet via a standard coiled cable(approximately 6-8 meters in length)and is hot-swappable.A built-in rechargeable lithium battery maintains the time and settings even when disconnected.
Features:It integrates a high-resolution color touchscreen,emergency stop button,enabling device,joystick,and function keys.The operator can safely move it around the robot by hand to perform operations such as robot programming,parameter setting,manual jogging,operation monitoring,and fault diagnosis.It supports multiple languagesand the graphical menu is intuitive and easy to use.
Technical parameters:Operating temperature is 0°C to 45°C,protection level is IP65,and it complies with IEC 60204-1,ISO 10218-1,CE,UL and other standards.
Analog input unit of ABB REG216 digital generator protection module
Basic information:It is part of the ABB REG216 digital generator protection module.
Functional features:It has 24 input channels that can be sampled simultaneously,with 6 channels per group.
Technical parameters:The sampling frequency is 600(720)Hz,the power frequency is 50(60)Hz,and the space required is two rack partitions.
