描述
ABB 216NG63 HESG441635R1是一款电源控制器，通常用于工业自动化和控制系统中。以下是其产品详情：
处理器：采用高效超标量RISC CPU。
通信协处理器：具备专用系统总线及控制器冗余连接通信的协处理器。
主存储器：有不同类型可供选择，如ABB PM802F主存储器采用静态RAM，具备电池保持功能，主电源故障恢复后可快速启动；ABB PM803F主存储器采用同步动态随机存储器(SDRAM)，也具备电池保持功能，但由于容量较大，保持时间比ABB PM802F短。
错误检查与修改：主存储器具有自动错误检查及修改能力(EDC单元)，可以检查2位错误及修改1位错误的数据字。
数据存储：硬件组态及诊测数据存储在16K位EEPROM脉冲串快速擦除EPROM中，用于快速ROM操作，这部分主要用于存储控制器固化程序，保证软件升级无需更换EPROM芯片。
通信接口：配备RS232串行接口，用于控制器诊测服务和无线时钟信号接口，该接口为标准9针D型接口，位于所有类型的电源模件上，同时支持冗余控制器模式的操作。
操作开关：所有类型的电源模件上还设置控制器基本操作的开关，如运行/停止工作开关，控制器复位开关，冗余手动切换开关。
状态显示：设置有控制器状态的LED显示。
电池功能：E1及E2槽具冗余电池供电功能，提供电池能量自动监控/报警及自动切换保持RAM数据功能。
温度监控：具备CPU主板温度监控功能，可周期性温度测量，并累积控制器正常与高温运行时间。
总线模件特性：所有现场总线模件可以在系统运行时，带电进行插拔；由于使用IC接口，1-F4槽总线模件可以自动识别和重新装载组态数据，实现既插既用功能。
其他功能：具有来自模件的数据错误信号识别及处理功能，每种总线模件产生多达4个不同中断源，每个模件预留地址域8MB用于内存访问，8MB用于I/O访问；内部工作电压监控；独立的”watchdog”模块用于保护操作系统的死锁现象；电池保持系统实时时钟；电源故障信号报警。
The ABB 216NG63 HESG441635R1 is a power supply controller commonly used in industrial automation and control systems.The following are product details:
Processor:Utilizes a high-efficiency superscalar RISC CPU.
Communications Coprocessor:A coprocessor with a dedicated system bus and redundant controller communication connections.
Main Memory:Different types are available.For example,the ABB PM802F uses static RAM with battery retention,enabling fast startup after a main power failure.The ABB PM803F uses synchronous dynamic random access memory(SDRAM)with battery retention,but due to its larger capacity,the retention time is shorter than that of the ABB PM802F.
Error Checking and Correction:The main memory features automatic error checking and correction(EDC unit),which can detect two-bit errors and correct single-bit errors in data words.Data Storage:Hardware configuration and diagnostic data are stored in a 16K-bit EEPROM(Electronic Programmable Memory)for fast ROM operation.This memory is primarily used to store controller firmware,ensuring software upgrades without replacing the EPROM chip.
Communication Interface:An RS232 serial interface is provided for controller diagnostics and a wireless clock signal interface.This standard 9-pin D-type interface is located on all power supply modules and supports redundant controller operation.
Operation Switches:All power supply modules also include switches for basic controller operations,such as run/stop,controller reset,and redundant manual mode.
Status Display:An LED displays the controller status.
Battery Function:The E1 and E2 slots feature redundant battery power,providing automatic battery life monitoring/alarms and automatic switching to retain RAM data.
Temperature Monitoring:The CPU motherboard temperature is monitored,periodically measuring the temperature and accumulating the controller’s normal and high-temperature operating time.Bus Module Features:All fieldbus modules can be plugged in and out while the system is running and powered on.Using an IC interface,the bus modules in slots 1-F4 automatically identify and reload configuration data,enabling plug-and-play functionality.
Other Features:Module-specific data error signal recognition and processing.Each bus module generates up to four different interrupt sources.Each module reserves 8MB of address space for memory access and 8MB for I/O access.Internal operating voltage monitoring;an independent”watchdog”module protects against operating system lockup;a battery maintains the system’s real-time clock;and a power failure alarm signal is provided.
