描述
ABB 216NG63A是一款高性能、高可靠性的电源控制器/变频器，由ABB公司生产，主要用于工业自动化系统中的电机控制和电源管理，具有精确的功率控制、多种保护功能和广泛的应用适应性，适用于制造业、可再生能源、交通运输等多个领域。
一、核心功能与技术规格
1.基本参数
产品型号：216NG63A
品牌/制造商：ABB
产品系列：控制系统/电源控制器
额定电压：380V
额定电流：63A
功率：710kW
速度范围：0至2000rpm
转矩范围：0至3500Nm
保护等级：IP20
重量：40 kg（部分型号）
2.性能特点
高效率：可减少发热量和功耗，提高系统整体效率
高功率密度：节省空间和重量，适合紧凑型安装环境
高可靠性：延长使用寿命，降低系统故障率
长使用寿命：降低维护成本，提高系统可用性
模块化设计：易于安装和维护，简化系统配置过程
数字控制技术：采用先进的数字控制技术和保护技术，确保电源输出稳定可靠12
3.保护功能
过载保护：有效防止系统过载导致的设备损坏
短路保护：在短路情况下快速切断电源，保护系统安全
过压保护：防止电压过高对系统造成损害
温度监测：实时监测系统温度，防止过热
浪涌保护：采用三级保护措施（TVS管限制电压、热敏电阻阻抗突增、气体放电管导通）
.The ABB 216NG63A is a high-performance,high-reliability power controller/inverter manufactured by ABB.It is primarily used for motor control and power management in industrial automation systems,featuring precise power control,multiple protection functions,and broad application adaptability,making it suitable for various fields such as manufacturing,renewable energy,and transportation.
I.Core Functions and Technical Specifications
1.Basic Parameters
Product Model:216NG63A
Brand/Manufacturer:ABB
Product Series:Control Systems/Power Controllers
Rated Voltage:380V
Rated Current:63A
Power:710kW
SpeedRange:0 to 2000rpm
Torque Range:0 to 3500Nm
Protection Class:IP20
Weight:40 kg(some models)
2.Performance Characteristics
High Efficiency:Reduces heat generation and power consumption,improving overall system efficiency.
High Power Density:Saves space and weight,suitable for compact installation environments.
High Reliability:Extends service life and reduces system failure rate.
Long Service Life:Reduces maintenance costs and improves system availability.
Modular Design:Easy to install and maintain,simplifying system configuration.
Digital Control Technology:Employs advanced digital control and protection technologies to ensure stable and reliable power output.
3.Protection Functions:
Overload Protection:Effectively prevents equipment damage caused by system overload.
Short Circuit Protection:Quickly cuts off power in the event of a short circuit,protecting system safety.
Overvoltage Protection:Prevents damage to the system caused by excessive voltage.
Temperature Monitoring:Monitors system temperature in real time to prevent overheating.
Surge Protection:Employs three-level protection measures(TVS diode voltage limiting,thermistor impedance surge,and gas discharge tube conduction).
