描述
ABB 3BSE008510R1 DO810是一款数字输出模块，属于ABB S800 I/O系列，通常用于工业自动化控制系统。具体产品详情如下：
基本信息：
品牌：ABB
型号：DO810，产品编号3BSE008510R1
产地：瑞典
安装方式：DIN导轨安装
电气参数：
工作电压：24V DC，电压范围为12-32V DC
输出电流：每通道最大0.5A
输出电压范围：10至30V
隔离电压：组间隔离，隔离电压为500V AC
物理参数：
尺寸：约100mm×80mm×35mm
重量：约0.26kg
功能特点：
多通道输出：具有16个数字输出通道，可同时控制多个执行器，输出分为两个独立隔离的8通道组，每组有电压监控输入。
保护功能：输出具备短路、过压和过热保护功能，每个输出通道都包含短路和过热保护高侧驱动器、EMC保护组件等。若电压消失，过程电压监控输入会给出通道错误信号，可通过ModuleBus读取。
状态指示：模块前端设有LED指示灯，方便用户观察输出状态。
通信接口：支持Profibus-DP V1等通信协议，可与控制系统通信，接收指令并转换为数字输出信号传递给外部设备。
应用领域：可应用于数控机械、冶金、石油天然气、化工、造纸印刷、纺织印染、汽车制造、电力自动化等工业领域，用于过程控制、机器控制等场景。
The ABB 3BSE008510R1 DO810 is a digital output module from the ABB S800 I/O series,commonly used in industrial automation control systems.Product details are as follows:
Basic Information:
Brand:ABB
Model:DO810,Part Number:3BSE008510R1
Origin:Sweden
Mounting Method:DIN Rail
Electrical Parameters:
Operating Voltage:24V DC,Voltage Range:12-32V DC
Output Current:Maximum 0.5A per channel
Output Voltage Range:10 to 30V
Isolation Voltage:Bank-to-bank isolation,500V AC
Physical Parameters:
Dimensions:Approximately 100mm×80mm×35mm
Weight:Approximately 0.26kg
Features:
Multi-channel Output:16 digital output channels,capable of controlling multiple actuators simultaneously.The outputs are organized into two independently isolated 8-channel groups,each with a voltage monitoring input.Protection:The outputs are protected against short circuit,overvoltage,and overtemperature.Each output channel includes a high-side driver with short-circuit and overtemperature protection,as well as EMC protection components.If voltage drops out,the process voltage monitoring input generates a channel error signal,which can be read via the ModuleBus.
Status Indicator:An LED indicator is located on the front of the module to easily monitor output status.
Communication Interface:Supporting protocols such as Profibus-DP V1,it communicates with control systems,receives commands,and converts them into digital output signals for transmission to external devices.
Applications:Suitable for process control and machine control in industries such as CNC machinery,metallurgy,oil and gas,chemicals,paper and printing,textile printing and dyeing,automotive manufacturing,and power automation.
