描述
ABB 3BSE013230R1是一款紧凑型终端模块，部件编号为TU810V1，主要用于连接现场布线与I/O模块，属于AC500-eCo系列。具体产品详情如下：
技术参数：
输入/输出通道：最大支持16路数字量信号（干接点/湿接点24V DC）或8路模拟量信号（0-10V/4-20mA）。
工作电压：24V DC（支持18-32V DC宽范围供电）。
额定绝缘电压：50V DC（通道间隔离）。
介电试验电压：500V AC（通道/地隔离）。
机械寿命：＞5000次插拔（无触点磨损）。
防护等级：IP20。
工作温度：-20℃至+60℃。
湿度范围：5%-95%（非冷凝）。
通信接口：支持S800 I/O总线、PROFIBUS DP协议。
尺寸重量：尺寸约为64mm×58.5mm×170mm，重量约0.261kg。
功能特点：
配置灵活：通过机械按键配置，支持多种I/O模块类型，并且具备双机械锁（36种组合），可防止错误插入I/O模块。
电气隔离：模块具有电气隔离功能，通道间500V AC隔离电压与S800 I/O总线屏蔽层设计，能确保信号的准确性和稳定性，防止干扰传播。
热拔插支持：支持热插拔，单条总线最多支持32个MTU，可灵活扩展系统。
应用领域：可广泛应用于流动性控制、模拟量I/O处理、串口通信、定时器和计数器等场景，适用于制造与过程工业中的数据采集与监测，也可用于石油化工过程控制、市政水处理监控、新能源发电系统等领域。
The ABB 3BSE013230R1 is a compact terminal module,part number TU810V1,primarily used to connect field wiring to I/O modules.It belongs to the AC500-eCo series.Product details are as follows:
Technical Parameters:
Input/Output Channels:Supports up to 16 digital signals(dry/wet contact,24V DC)or 8 analog signals(0-10V/4-20mA).
Operating Voltage:24V DC(supports a wide range of 18-32V DC power supply).
Rated Insulation Voltage:50V DC(channel-to-channel isolation).
Dielectric Test Voltage:500V AC(channel-to-ground isolation).
Mechanical Life:>5000 plugging and unplugging cycles(no contact wear).
Protection Rating:IP20.
Operating Temperature:-20°C to+60°C.
Humidity Range:5%-95%(non-condensing).Communication Interface:Supports S800 I/O bus and PROFIBUS DP protocol.
Dimensions and Weight:Approximately 64mm×58.5mm×170mm,weighs approximately 0.261kg.
Features:
Flexible Configuration:Mechanically configured,supports a variety of I/O module types.Dual mechanical locks(36 possible combinations)prevent incorrect I/O module insertion.
Electrical Isolation:The modules feature electrical isolation,with 500V AC isolation between channels and the S800 I/O bus shielding design,ensuring signal accuracy and stability and preventing interference.
Hot-Swap Support:Hot-swapping is supported,with a single bus supporting up to 32 MTUs,enabling flexible system expansion.
Applications:Widely applicable to flow control,analog I/O processing,serial communication,timers,and counters.Suitable for data acquisition and monitoring in manufacturing and process industries,as well as petrochemical process control,municipal water treatment monitoring,and renewable energy power generation systems.
