描述
ABB 3BSE018172R1是一款可充电电池单元，型号为SB822。它专为AC 800M控制器提供扩展内存备份，同时在主电源故障时作为外部电源，确保系统持续运行，防止数据丢失。以下是具体详情：
安装方式：采用DIN导轨安装，便于在控制柜内集成和固定。
电池类型：可充电锂离子电池。
额定输出电压：3.6V。
最大输出电流：0.05A。
工作温度范围：最高可达60℃。
防护等级：IP20，符合IEC 60529标准。
尺寸：宽度85.8毫米，深度58.5毫米，高度136毫米。
重量：约550克。
配件：包含24V DC连接器和长度为2米的连接电缆（型号TK821V020）。
The ABB 3BSE018172R1 is a rechargeable battery unit,model SB822.It is designed to provide extended memory backup for AC 800M controllers and serve as an external power source in the event of a main power failure,ensuring continuous system operation and preventing data loss.Specific details are as follows:
Mounting method:DIN rail mount for easy integration and mounting within a control cabinet.
Battery type:Rechargeable lithium-ion battery.
Rated output voltage:3.6V.
Maximum output current:0.05A.
Operating temperature range:Up to 60°C.
Protection rating:IP20,in accordance with IEC 60529.
Dimensions:Width 85.8 mm,Depth 58.5 mm,Height 136 mm.
Weight:Approximately 550 grams.
Accessories:Includes a 24V DC connector and a 2-meter connecting cable(model TK821V020).
