描述
ABB 3BSE018172R1是一款可充电电池单元，型号为SB822，主要用于为AC 800M控制器提供扩展内存备份。以下是其详细信息：
安装方式：采用DIN导轨安装，便于在控制柜内集成和固定。
组成部分：包含锂离子电池、24V DC连接器和长度为2米的连接电缆（型号TK821V020）。
主要特点：在主电源故障时，SB822作为外部电源，为AC 800M控制器提供备用电源，确保系统的持续运行，防止数据丢失。
技术参数：
额定输出电压：3.6V
最大输出电流：0.05A
工作温度范围：最高可达60℃
防护等级：IP20，符合IEC 60529标准
尺寸：宽度85.8毫米，深度58.5毫米，高度136毫米
重量：约550克
ABB’s 3BSE018172R1 rechargeable battery unit,model SB822,is primarily used to provide extended memory backup for the AC 800M controller.Details are as follows:
Mounting Method:DIN rail mountable for easy integration and mounting within a control cabinet.
Components:Includes a lithium-ion battery,a 24V DC connector,and a 2-meter connecting cable(model TK821V020).
Key Features:In the event of a main power failure,the SB822 acts as an external power supply,providing backup power to the AC 800M controller,ensuring continuous system operation and preventing data loss.
Technical Parameters:
Rated Output Voltage:3.6V
Maximum Output Current:0.05A
Operating Temperature Range:Up to 60°C
Protection Rating:IP20,in accordance with IEC 60529
Dimensions:Width 85.8mm,Depth 58.5mm,Height 136mm
Weight:Approximately 550g
