描述
ABB 3BSE020510R1 DO801是一款数字输出模块，属于ABB S800 I/O系列。以下是其详细信息：
基本参数：
型号：3BSE020510R1 DO801
尺寸：约93mm×136mm×51mm
重量：约0.24kg
原产国：瑞典
电气参数：
工作电压：24V DC
输出电压范围：10-30V DC
最大连续输出电流：0.5A
通道数：16通道
输出类型：数字输出
隔离情况：16个通道分为1组，组内通道相互隔离
功能特点：
保护功能：每个通道都配备了短路和过热保护的高侧驱动器、EMC保护组件、电感负载抑制等，具有接地和30V短路保护、过压和过温保护功能。
状态指示：具备输出状态指示LED，可直观显示输出状态。
预定状态设置：OSP（输出状态保持）功能可在通信错误时将输出设置为预定状态。
连接方式：通过可拆卸连接器进行过程和电源连接，方便安装和维护。
通信协议：支持Profibus-DP、Modbus RTU等通信协议，可与ABB的PLC系统和其他网络无缝集成。
应用领域：广泛应用于制造业、能源与公用事业、交通与运输、建筑与基础设施等任何需要数字输出控制的工业自动化领域。
The ABB 3BSE020510R1 DO801 is a digital output module that belongs to the ABB S800 I/O series.The following are its details:
Basic Parameters:
Model:3BSE020510R1 DO801
Dimensions:Approximately 93mm×136mm×51mm
Weight:Approximately 0.24kg
Country of Origin:Sweden
Electrical Parameters:
Operating Voltage:24V DC
Output Voltage Range:10-30V DC
Maximum Continuous Output Current:0.5A
Number of Channels:16
Output Type:Digital
Isolation:16 channels are grouped into groups,and channels within a group are isolated from each other.
Features:
Protection:Each channel is equipped with a high-side driver with short-circuit and overtemperature protection,EMC protection components,inductive load suppression,and protection against ground faults,short-circuit to 30V,overvoltage,and overtemperature.
Status Indicator:Output status LEDs provide intuitive display of output status.Predetermined State Setting:The OSP(Output State Hold)function resets the output to a predetermined state in the event of a communication error.
Connectivity:Process and power connections are made via removable connectors,simplifying installation and maintenance.
Communication Protocols:Support for protocols such as Profibus-DP and Modbus RTU enables seamless integration with ABB PLC systems and other networks.
Applications:Widely applicable to industrial automation applications requiring digital output control,including manufacturing,energy and utilities,transportation,and building and infrastructure.
