描述
ABB 3EHE300694R0001 PPA425是一款工业级电源模块，专为严苛环境下的稳定供电设计。以下是基于多源信息整合的产品详情：
一、核心参数与功能
电气规格
输入电压范围：支持宽幅交流输入（90-250V AC），部分配置可兼容85-264V AC，确保在不同电网环境下稳定运行。
输出特性：提供24V DC/40A的持续供电能力，部分型号可配置12V DC/5A输出，满足不同负载需求。
效率与功率因数：采用高效拓扑设计，效率≥94%，功率因数≥0.9，符合能源管理要求。
物理特性
尺寸与重量：标准型号尺寸为120mm×100mm×60mm，重量约1.2kg；紧凑型设计（如PPA425 B01）尺寸为74mm×48mm×44mm，重量0.3kg。
防护等级：IP20防护等级，可抵御灰尘和垂直滴落的液体。
安装方式：支持DIN导轨或壁挂式安装，便于集成到控制柜中。
可靠性设计
环境适应性：工作温度范围为-20°C至+55°C，部分型号可扩展至-40°C至+85°C存储温度。
保护机制：内置过压、过流、过热保护，确保异常工况下的设备安全。
认证合规：通过CE、UL、CSA认证，符合国际安全标准。
二、应用场景
工业自动化
为PLC、传感器、执行器等设备提供稳定电源，适用于包装机械、纺织设备、食品加工生产线等场景。
能源管理
支持分布式能源系统（如光伏逆变器）的电源分配，可与储能设备协同工作。
过程控制
在石油化工、水处理等领域，为DCS系统和现场仪表提供可靠电力，确保实时数据采集与控制。
三、接口与兼容性
通信接口
部分型号集成Modbus RTU或Ethernet/IP接口，可与上位机进行状态监控和参数配置。
连接方式
采用4-pin XLR接口（PPA425 B01）或螺钉端子，支持快速插拔和防误操作设计。
The ABB 3EHE300694R0001 PPA425 is an industrial-grade power module designed for stable power supply in harsh environments.The following product details are based on information from multiple sources:
I.Core Parameters and Features
Electrical Specifications
Input Voltage Range:Supports a wide AC input range(90-250V AC),with some configurations compatible with 85-264V AC,ensuring stable operation in diverse power grid environments.
Output Characteristics:Provides 24V DC/40A continuous power supply capability,with some models configurable for 12V DC/5A output to meet diverse load requirements.
Efficiency and Power Factor:Utilizing a high-efficiency topology,it achieves≥94%efficiency and≥0.9 power factor,meeting energy management requirements.
Physical Characteristics
Dimensions and Weight:The standard model measures 120mm×100mm×60mm and weighs approximately 1.2kg.Compact designs(such as the PPA425 B01)measure 74mm×48mm×44mm and weigh 0.3kg.Protection Rating:IP20 rated,protects against dust and vertically dripping liquids.
Mounting Method:Supports DIN rail or wall mounting for easy integration into control cabinets.
Reliable Design
Environmental Adaptability:Operating temperature range is-20°C to+55°C,with storage temperature extended to-40°C to+85°C for some models.
Protection Mechanism:Built-in overvoltage,overcurrent,and overtemperature protection ensures device safety under abnormal operating conditions.
Certification and Compliance:CE,UL,and CSA certified,meeting international safety standards.
II.Application Scenarios
Industrial Automation
Provides stable power for PLCs,sensors,actuators,and other equipment,suitable for packaging machinery,textile equipment,food processing production lines,and other applications.
Energy Management
Supports power distribution for distributed energy systems(such as photovoltaic inverters)and can work in conjunction with energy storage devices.
Process Control
In petrochemical,water treatment,and other fields,it provides reliable power for DCS systems and field instruments,ensuring real-time data acquisition and control.III.Interfaces and Compatibility
Communication Interface
Some models feature integrated Modbus RTU or Ethernet/IP interfaces,enabling communication with a host computer for status monitoring and parameter configuration.
Connection Method
A 4-pin XLR connector(PPA425 B01)or screw terminals are available,supporting quick plug-in and unplugging and preventing accidental operation.
