一、产品定位与核心功能
模块类型
-安全模块/通信接口：集成于ABB机器人控制系统（如IRB系列），支持冗余现场总线（2 Mbps）通信，保障工业场景的高可靠性；
-操作主板单元：部分供应商标注其为PLC/DCS系统的控制板，用于信号处理与I/O管理。
核心功能
-数据转换与传输：∑-Δ架构实现每25毫秒一次高精度模拟输入采样，支持工频噪声过滤；
-冗余设计：双电源输入、冗余总线连接，确保系统容错性；
-状态监测：LED指示灯实时显示模块运行状态（如电源、通信、故障报警）。
二、技术参数
|项目|参数/功能|
|通信协议|2 Mbps冗余现场总线（支持Modbus扩展）|
|电源需求|24V DC（独立电源或冗余供电）|
|环境适应性|工作温度：-20°C至60°C；防护等级：IP20|
|物理接口|DIN导轨安装；TAS终端组件兼容性强|
三、应用场景
工业机器人
-IRB 6700/7600系列的关节控制与安全连锁；
-弧焊、搬运等场景的实时信号传输。
过程自动化
-水处理、水泥厂中的泵与阀门控制；
-液压系统压力监测与流量调节。
1.Product positioning and core functions
Module Type
-Safety module/communication interface:integrated into ABB robot control system(such as IRB series),supports redundant fieldbus(2 Mbps)communication,ensuring high reliability in industrial scenarios;
-Operation motherboard unit:Some suppliers are marked as the control board of PLC/DCS system,used for signal processing and I/O management.
Core functions
-Data conversion and transmission:The∑-Δarchitecture realizes high-precision analog input sampling every 25 milliseconds,supporting industrial frequency noise filtering;
-Redundant design:dual power input and redundant bus connection to ensure system fault tolerance;
-Status monitoring:LED indicators display the module’s operating status(such as power supply,communication,fault alarm)in real time.
2.Technical parameters
|Project|Parameters/Functions|
|Communication Protocol|2 Mbps Redundant Fieldbus(Supports Modbus Extension)|
|Power requirements|24V DC(independent power supply or redundant power supply)|
|Environmental adaptability|Operating temperature:-20°C to 60°C;Protection level:IP20|
|Physical interface|DIN rail installation;TAS terminal components are highly compatible|
III.Application scenarios
Industrial robots
-Joint control and safety chain of IRB 6700/7600 series;
-Real-time signal transmission in arc welding,handling and other scenarios.
Process automation
-Water treatment,pump and valve control in cement plants;
-Hydraulic system pressure monitoring and flow regulation.
