描述
一、产品定位与核心功能
模块类型
-电源分配单元：为机器人控制柜内的I/O模块、传感器等设备提供稳定24V DC电源；
-信号隔离与保护：支持断线检测、过流保护，防止系统误动作。
核心功能
-多通道供电：内置16路独立电源输出，支持并联或独立控制；
-状态监测：通过LED指示灯实时显示电源状态（就绪、故障报警）；
-兼容性：适配ABB IRC5控制器，支持冗余总线通信。
二、技术参数
|项目|参数/功能|
|输入电源|24V DC（需外部供电，电流≥250mA）|
|输出通道|16路独立24V DC（每路负载≤2A）|
|检测功能|断线报警（红色LED）、电源故障指示|
|物理特性|尺寸：110×83.5×165mm；重量：0.42kg|
三、应用场景
工业机器人控制柜
-IRB 120/140系列的电源分配与信号隔离；
-多关节机器人（如码垛、焊接）的外围设备供电。
自动化产线集成
-分配电柜中的传感器、电磁阀等低功耗设备；
-洁净室环境下的稳定供电（支持IP40防护）。
1.Product positioning and core functions
Module Type
-Power distribution unit:Provides a stable 24V DC power supply for I/O modules,sensors and other equipment in the robot control cabinet;
-Signal isolation and protection:supports disconnection detection and overcurrent protection to prevent system malfunction.
Core functions
-Multi-channel power supply:built-in 16 independent power output,supporting parallel or independent control;
-Status monitoring:Real-time display of power status(ready,fault alarm)through LED indicators;
-Compatibility:Adaptable to ABB IRC5 controller and supports redundant bus communication.
2.Technical parameters
|Project|Parameters/Functions|
|Input power supply|24V DC(external power supply required,current≥250mA)|
|Output Channel|16 independent 24V DC(load per channel≤2A)|
|Detection function|Disconnection alarm(red LED),power supply fault indication|
|Physical Characteristics|Dimensions:110×83.5×165mm;Weight:0.42kg|
III.Application scenarios
Industrial robot control cabinet
-Power distribution and signal isolation for IRB 120/140 series;
-Powered by peripheral equipment of multi-joint robots(such as palletization,welding).
Automated production line integration
-Distribute low-power equipment such as sensors,solenoid valves in electrical cabinets;
-Stable power supply in clean room environment(supports IP40 protection).
