描述
ABB 3HAC031670-001产品详情
ABB 3HAC031670-001是工业机器人PROFINET通讯板（型号DSQC 688），专为ABB机器人控制柜设计，用于实现高速以太网通信与数据交换，广泛应用于汽车制造、智能仓储等自动化场景。以下是基于多来源技术文档及供应商信息的综合说明：
一、产品定位与核心功能
模块类型
-PROFINET通讯板：支持EtherNet/IP、PROFINET协议，实现机器人与上位机或PLC的实时数据交互；
-接口扩展：集成RJ45以太网接口（10/100/1000Mbps）及光纤接口（可选）。
核心功能
-高速通信：数据传输速率可达1Gbps，支持同步运动控制（抖动＜1ms）；
-协议兼容性：适配西门子、施耐德等品牌PLC的工业通信标准；
-诊断功能：通过Web服务器实时监控网络状态，支持故障日志导出。
二、技术参数
|项目|参数/功能|
|电源需求|24V DC（允许波动±15%）|
|通信接口|1×RJ45（PoE供电）、1×光纤（多模/单模可选）|
|工作环境|温度：-20°C至+60°C；湿度：5%–95%（非冷凝）|
|物理特性|尺寸：114×257×80mm；重量：0.5kg|
三、应用场景
工业机器人控制
-IRB 6700/7600系列的高速数据传输（如焊接、喷涂）；
-多机器人协作系统（如汽车总装线）的同步控制。
智能制造集成
-与西门子S7-1500 PLC协同，构建MES系统数据采集节点；
-工业物联网（IIoT）中的边缘计算设备通信。
ABB 3HAC031670-001 Product details
ABB 3HAC031670-001 is an industrial robot PROFINET communication board(model DSQC 688),designed for ABB robot control cabinet,used to realize high-speed Ethernet communication and data exchange,and is widely used in automation scenarios such as automobile manufacturing and intelligent warehousing.The following is a comprehensive description based on multi-source technical documents and supplier information:
1.Product positioning and core functions
Module Type
-PROFINET communication board:supports EtherNet/IP and PROFINET protocols to realize real-time data interaction between robots and host computers or PLCs;
-Interface extension:Integrated RJ45 Ethernet interface(10/100/1000Mbps)and fiber optic interface(optional).
Core functions
-High-speed communication:The data transmission rate can reach 1Gbps,and supports synchronous motion control(jitter<1ms);
-Agreement compatibility:industrial communication standards adapted to Siemens,Schneider and other brands of PLCs;
-Diagnostic function:Monitor network status in real time through the web server,and supports fault log export.
2.Technical parameters
|Project|Parameters/Functions|
|Power requirements|24V DC(permitted fluctuation±15%)|
|Communication interface|1×RJ45(PoE powered),1×fiber(multi-mode/single-mode optional)|
|Working Environment|Temperature:-20°C to+60°C;Humidity:5%–95%(non-condensing)|
|Physical Characteristics|Dimensions:114×257×80mm;Weight:0.5kg|
III.Application scenarios
Industrial robot control
-High-speed data transmission(such as welding,spraying)of IRB 6700/7600 series;
-Synchronous control of multi-robot collaboration systems(such as automotive assembly lines).
Intelligent manufacturing integration
-Cooperate with Siemens S7-1500 PLC to build a MES system data acquisition node;
-Communication of edge computing device in the Industrial Internet of Things(IIoT).
