描述
额定参数：
额定电流（In）：根据型号推测可能为特定范围（如630A-1600A，需确认具体配置）。
额定电压（Ue）：通常为400VAC（三相）或230VAC（单相），适用于低压配电系统。
短路分断能力（Icu/Ics）：可能达到70kA（根据型号前缀“70”推测），满足高短路电流场景需求。
保护功能：
过载保护：通过电子脱扣器实现反时限特性，保护电机和线路免受过载损害。
短路保护：瞬时或短延时脱扣，快速切断故障电流。
接地故障保护：可选配，检测线路对地漏电流，提高安全性。
欠压/过压保护：监测电压异常，防止设备损坏。
智能化功能：
测量与监控：内置电流、电压、功率、能量等参数测量，支持实时监控和数据分析。
通信接口：支持Modbus、Profibus、EtherNet/IP等工业协议，可集成到SCADA或能源管理系统。
区域选择性联锁（ZSI）：与上下游断路器协调动作，减少停电范围。
能量管理：优化电能使用，降低能耗成本。
机械参数：
极数：根据型号推测可能为2极（需确认），另有3极、4极版本可选。
安装方式：抽屉式或固定式，便于维护和更换。
操作机构：电动或手动操作，支持远程控制。
四、应用场景
工业领域：
工厂配电系统，保护电机、变频器等关键设备。
自动化生产线，确保供电连续性。
商业建筑：
购物中心、写字楼等大型建筑的低压配电柜。
消防系统、电梯等重要负载的保护。
基础设施：
数据中心、医院、机场等对供电可靠性要求极高的场所。
新能源领域（如光伏、风电）的并网保护。
Rated Parameters:
Rated Current(In):Depending on the model,this may be within a specific range(e.g.,630A-1600A;specific configurations must be confirmed).
Rated Voltage(Ue):Typically 400VAC(three-phase)or 230VAC(single-phase),suitable for low-voltage power distribution systems.
Short-Circuit Breaking Capacity(Icu/Ics):This may reach 70kA(based on the”70″prefix in the model number),meeting the requirements of high short-circuit current scenarios.
Protection Functions:
Overload Protection:An electronic trip unit provides inverse-time characteristics to protect motors and lines from overload damage.
Short-Circuit Protection:Instantaneous or short-delay tripping quickly interrupts fault current.
Ground Fault Protection:Optional,detects line-to-ground leakage current for enhanced safety.
Undervoltage/Overvoltage Protection:Detects voltage anomalies to prevent equipment damage.
Intelligent Functions:
Measurement and Monitoring:Built-in measurement of current,voltage,power,energy,and other parameters supports real-time monitoring and data analysis.Communication Interface:Supports industrial protocols such as Modbus,Profibus,and EtherNet/IP,allowing integration into SCADA or energy management systems.
Zone Selective Interlocking(ZSI):Coordinates operation with upstream and downstream circuit breakers to minimize the scope of power outages.
Energy Management:Optimizes power usage and reduces energy costs.
Mechanical Parameters:
Number of Poles:Based on the model,it is likely 2-pole(subject to confirmation);3-pole and 4-pole versions are also available.
Mounting:Drawer-mounted or fixed-mount for easy maintenance and replacement.
Operating Mechanism:Electric or manual operation,with remote control support.
IV.Application Scenarios
Industrial:
Factory power distribution systems,protecting key equipment such as motors and inverters.
Automated production lines,ensuring power supply continuity.
Commercial Buildings:
Low-voltage distribution cabinets in large buildings such as shopping malls and office buildings.
Protection of critical loads such as fire protection systems and elevators.
Infrastructure:
Data centers,hospitals,airports,and other locations with extremely high power supply reliability requirements.
Grid-connected protection for renewable energy sources(such as photovoltaic and wind power).
