描述
ABB 800PP846A是ABB公司Panel 800系列中的标准操作面板，属于工业自动化控制系统中的关键人机交互设备，具备高分辨率显示、多协议通信能力及坚固耐用的设计，专为恶劣工业环境下的稳定运行而设计，广泛应用于过程自动化、制造和能源管理等领域。
一、基础信息与产品定位
1.基本参数
产品型号：800PP846A（属于Panel 800系列）
品牌/制造商：ABB（全球领先的工业自动化技术企业）
产品类型：标准操作面板（HMI人机界面）
系列定位：Panel 800系列中的按键式标准面板，与触摸式面板PP815A、PP825A等形成完整产品线
原产地：美国
2.物理特性
外壳材质：坚固而轻质的压铸粉末涂层铝外壳，提供工业级防护
防护等级：IP66/IP65，能够承受潮湿、多尘和苛刻的工业环境
工作温度范围：-10°C至+60°C（部分资料提及-30°C至70°C）
湿度适应性：最高95%相对湿度（无凝结）
重量：约1.0kg，便于安装和维护23
二、技术规格与功能特点
1.核心配置
处理器：工业级ARM9嵌入式微处理器，主频为200/400MHz
内存配置：64MB SDRAM+128MB NAND Flash，确保快速响应和数据存储
显示系统：高分辨率TFT/LED显示屏，提供清晰的图像和文本显示
用户界面：按键式操作界面（区别于触摸屏型号），适合需要物理按键反馈的工业场景
The ABB 800PP846A is the standard operator panel in ABB’s Panel 800 series.It is a key human-machine interface device in industrial automation control systems,featuring a high-resolution display,multi-protocol communication capabilities,and a rugged design.Specifically designed for stable operation in harsh industrial environments,it is widely used in process automation,manufacturing,and energy management.
I.Basic Information and Product Positioning
1.Basic Parameters
Product Model:800PP846A(belongs to the Panel 800 series)
Brand/Manufacturer:ABB(a leading global industrial automation technology company)
Product Type:Standard Operation Panel(HMI)
Series Positioning:A button-type standard panel in the Panel 800 series,forming a complete product line with touch panels such as PP815A and PP825A
Country of Origin:USA
2.Physical Characteristics
Housing Material:Robust and lightweight die-cast powder-coated aluminum housing,providing industrial-grade protection
Protection Rating:IP66/IP65,capable of withstanding humid,dusty,and harsh industrial environments
Operating Temperature Range:-10°C to+60°C(some sources mention-30°C to 70°C)
Humidity Adaptability:Up to 95%relative humidity(non-condensing)
Weight:Approximately 1.0kg,easy to install and maintain
II.Technical Specifications and Functional Features
1.Core Configuration:
Processor:Industrial-grade ARM9 embedded microprocessor,clock speed 200/400MHz
Memory Configuration:64MB SDRAM+128MB NAND Flash,ensuring fast response and data storage
Display System:High-resolution TFT/LED display,providing clear image and text display
User Interface:Button-based operation interface(distinct from touchscreen models),suitable for industrial scenarios requiring physical button feedback
