描述
1.产品定位与分类
ABB 83SR04C-E是ABB公司推出的高性能超声波传感器，属于工业级距离测量与物位检测设备，专为恶劣工业环境设计。其核心功能包括：
非接触式距离测量：通过超声波反射原理检测目标物与传感器之间的距离。
物位监测：适用于液体、固体颗粒或粉末的液位/料位控制。
过程自动化集成：可与PLC、DCS等控制系统无缝对接，实现自动化流程控制。
典型应用场景：
工厂自动化：物料搬运、包装机械、机器人导航中的障碍物检测。
过程工业：化工储罐液位监测、食品加工原料料位控制。
物流与仓储：输送带物料检测、堆垛机高度定位。
水处理：水池水位测量、污水泵站液位控制。
2.关键技术参数
2.1基础规格
参数项详细说明
型号变体83SR04C-E（“E”通常表示增强型或出口版，可能包含特定通信协议或防护等级）
外壳材质不锈钢（316L）（耐腐蚀，适用于化工/食品行业）
防护等级IP67（防尘防水，可短期浸水）
尺寸直径：50mm
长度：100mm（含安装螺纹）
重量约300g
工作温度-20℃~+70℃（工业级宽温设计）
存储温度-40℃~+85℃
压力范围-0.1~3bar（相对压力）
2.2测量性能参数
参数项详细说明
测量原理脉冲超声波（40kHz）（抗干扰能力强，适合长距离测量）
测量范围200mm~6000mm（依型号配置，典型值：5000mm）
分辨率1mm（最小可区分距离变化）
重复性±0.5%of full scale（如5000mm量程时重复性≤25mm）
线性度±0.2%of full scale（经过温度补偿校准）
响应时间<200ms（从触发到输出有效信号）
盲区200mm（传感器前方无法检测的最小距离）
2.3输出与接口参数
参数项详细说明
模拟输出4~20mA（两线制，负载电阻≤500Ω）
数字输出NPN/PNP可切换（最大负载电流：300mA）
通信协议Modbus RTU（RS485接口）
可选PROFIBUS DP、DeviceNet（需定制）
同步功能支持外部触发输入（如PLC脉冲信号触发测量）
显示与调试内置LED指示灯（电源、测量状态、故障提示）
可选HMI调试模块
2.4电气参数
参数项详细说明
供电电压12~30V DC（典型值：24V DC）
功耗<2W（静态）
<5W（峰值发射时）
绝缘电阻>100MΩ（500V DC测试）
电磁兼容EN 61000-6-2（工业环境抗干扰）
EN 61000-6-4（工业环境辐射发射）
2.5安全与认证
参数项详细说明
安全标准CE（欧盟安全认证）
UL（美国安全认证）
防爆认证可选ATEX Zone 2/22（适用于易燃易爆环境）
环保认证RoHS（无铅化）
REACH（化学品合规）
1.Product Positioning and Classification
The ABB 83SR04C-E is a high-performance ultrasonic sensor from ABB.It is an industrial-grade distance measurement and level detection device designed for harsh industrial environments.Its core functions include:
Non-contact distance measurement:Detects the distance between the target and the sensor using the ultrasonic reflection principle.
Level monitoring:Suitable for level control of liquids,solid particles,or powders.
Process automation integration:Seamlessly integrates with control systems such as PLCs and DCSs to achieve automated process control.
Typical application scenarios:
Factory automation:Obstacle detection in material handling,packaging machinery,and robotic navigation.
Process industries:Level monitoring of chemical storage tanks and level control of raw materials in food processing.
Logistics and warehousing:Material detection on conveyor belts and height positioning of stacking cranes.
Water treatment:Water level measurement in pools and level control in sewage pumping stations.2.Key Technical Specifications
2.1 Basic Specifications
Parameter Item Detailed Description
Model Variant 83SR04C-E(“E”typically indicates an enhanced or export version and may include specific communication protocols or protection ratings)
Case Material Stainless Steel(316L)(Corrosion-resistant,suitable for the chemical and food industries)
Protection Rating IP67(Dustproof and waterproof,withstands short-term submersion in water)
Dimensions Diameter:50mm
Length:100mm(including mounting threads)
Weight Approximately 300g
Operating Temperature-20°C to+70°C(Industrial-grade wide temperature design)
Storage Temperature-40°C to+85°C
Pressure Range-0.1 to 3 bar(relative pressure)
2.2 Measurement Performance Parameters
Parameter Item Detailed Description
Measurement Principle Pulsed Ultrasonic Wave(40kHz)(Strong anti-interference capability,suitable for long-distance measurement)
Measuring Range 200mm to 6000mm(depending on model configuration,typical value:5000mm)
Resolution 1mm(minimum detectable distance change)
Repeatability±0.5%of full scale Scale(e.g.,repeatability≤25mm at 5000mm range)
Linearity±0.2%of full scale(after temperature compensation)
Response time<200ms(from trigger to valid signal output)
Blind zone 200mm(the minimum distance in front of the sensor that cannot be detected)
2.3 Output and Interface Parameters
Parameter Detailed Description
Analog output 4-20mA(two-wire,load resistance≤500Ω)
Digital output NPN/PNP switchable(maximum load current:300mA)
Communication protocol Modbus RTU(RS485 interface)
Optional PROFIBUS DP and DeviceNet(customizable)
Synchronization function Supports external trigger input(e.g.,PLC pulse signal triggering measurement)
Display and Debugging:Built-in LED indicators(power,measurement status,fault indication)
Optional HMI debugging module
2.4 Electrical Parameters
Parameter Detailed Description
Supply voltage 12-30V DC(typical:24V DC)
Power consumption<2W(static)
<5W(peak emission)
Insulation resistance>100MΩ(500V DC test)
Electromagnetic compatibility EN 61000-6-2(immunity for industrial environments)
EN 61000-6-4(radiated emissions for industrial environments)
2.5 Safety and Certifications
Parameter Detailed Description
Safety Standards CE(European Union Safety Certification)
UL(US Safety Certification)
Explosion-proof certification Optional ATEX Zone 2/22(suitable for flammable and explosive environments)
Environmental Certifications RoHS(lead-free)
REACH(chemical compliance)
