描述
ABB ACS800是一系列高性能的变频器，型号ACS800 0016-3可能具体为ACS800-01-0016-3或ACS800-11-0016-3等，以下是相关产品详情：
ACS800-01-0016-3：
功率与电流：最大连续功率（P cont.max）为11kW，最大连续电流（I cont.max）为25A。重载应用时，输出功率为7.5kW，输出电流为19A；正常使用时，输出功率为11kW，输出电流为25A。
电压与频率：输入电压为380-415V，输入频率为48-63Hz，输出频率范围为0-300Hz。
物理特性：采用壁挂式安装，产品净重量约为14kg，尺寸约为471mm×265mm×173mm。
其他参数：防护等级为IP21，1分钟过载能力为150%。
ACS800-11-0016-3：
功率与电流：最大连续功率（P cont.max）为15kW，最大连续电流（I cont.max）为34A。
物理特性：框架尺寸为R5，产品净重量为65kg，尺寸约为389mm×814mm×265mm。
ACS800系列变频器采用直接转矩控制（DTC）技术，能为异步电动机同时提供精确的位置、同步控制、DTC性能和高过载能力。并且具有多种功能，如增强的PFC应用可控制多个泵，SPFC循环软起功能可依次调节泵，还具备多点U/F曲线、超越模式、内置PID调节器等。同时，该系列变频器安装简单，可并排安装，通过多种I/O连接和即插式可选件可方便地连接到现场总线系统上。
ABB’s ACS800 series of high-performance frequency converters.The ACS800 0016-3 model may be designated as ACS800-01-0016-3 or ACS800-11-0016-3.The following are product details:
ACS800-01-0016-3:
Power and Current:Maximum continuous power(Pcont.max)is 11 kW,and maximum continuous current(Icont.max)is 25 A.In heavy-duty applications,output power is 7.5 kW and output current is 19 A;in normal use,output power is 11 kW and output current is 25 A.
Voltage and Frequency:Input voltage is 380-415 V,input frequency is 48-63 Hz,and output frequency range is 0-300 Hz.Physical Characteristics:Wall-mountable,net weight approximately 14 kg,dimensions approximately 471 mm×265 mm×173 mm.
Other Parameters:Protection rating IP21,1-minute overload capacity 150%.
ACS800-11-0016-3:
Power and Current:Maximum continuous power(Pcont.max)15 kW,maximum continuous current(Icont.max)34 A.
Physical Characteristics:Frame size R5,net weight 65 kg,dimensions approximately 389 mm×814 mm×265 mm.
The ACS800 series inverter utilizes direct torque control(DTC)technology,providing precise position control,synchronous control,DTC performance,and high overload capacity for asynchronous motors.They also offer a variety of features,such as enhanced PFC applications for controlling multiple pumps,SPFC cycle soft-start functionality for sequentially regulating pumps,multi-point U/F curves,override mode,and a built-in PID regulator.These drives are also easy to install,can be installed side-by-side,and can be easily connected to fieldbus systems through a variety of I/O connections and plug-in options.
