描述
一、产品概述
ABB AO820是ABB推出的一款高性能模拟量输出模块，属于其自动化控制系统（如ABB 800xA、AC500系列或工业IT解决方案）的核心组件。该模块设计用于将控制系统生成的数字信号转换为工业现场所需的模拟信号（如电压、电流），以驱动执行机构（如阀门、变频器、调节器等），广泛应用于过程控制、能源管理、智能制造及环境监测等领域。
二、核心特性
多通道高精度输出
通道数量：通常支持8路独立模拟量输出通道（部分型号可能扩展至16路）。
输出类型：可配置为电压（如±10V、0-10V）或电流（如0-20mA、4-20mA）信号，满足不同执行机构需求。
分辨率：16位（部分型号支持24位），确保输出信号的平滑性和精确性。
精度：±0.1%FS（满量程），适用于高精度控制场景。
工业级可靠性设计
工作温度范围：-20℃至+70℃（扩展型号支持-40℃至+85℃），适应极端环境。
防护等级：IP20（机柜内安装），可选IP65防护外壳用于户外或恶劣场景。
隔离保护：通道间及通道与总线间隔离电压达1500V AC，防止信号干扰和设备损坏。
抗干扰能力：内置电磁兼容（EMC）滤波器，符合IEC 61000-4标准，有效抑制工业噪声。
灵活通信与集成
通信协议：支持PROFIBUS-DP、Modbus RTU/TCP、EtherCAT或ABB专用协议（如ABB Totalflow），与主流PLC/DCS系统无缝兼容。
总线接口：采用标准化接口（如RJ45或D-sub），简化布线与维护。
热插拔功能：支持带电插拔，减少系统停机时间。
智能诊断与维护
实时监测：每通道独立状态检测（如断线、短路、过载），并通过LED指示灯或控制系统报警。
在线标定：支持软件远程校准，无需手动调整电位器。
自诊断功能：模块内置故障检测逻辑，可记录最后100条事件日志，便于故障追溯。
三、技术参数
参数类别详情
型号AO820
通道数8路（可扩展至16路）
输出类型电压：±10V、0-10V；电流：0-20mA、4-20mA（可软件配置）
分辨率16位（可选24位）
精度±0.1%FS（典型值）
负载能力电压输出：≥1kΩ；电流输出：≤500Ω
更新速率≤10ms/通道（全通道同步更新）
通信接口PROFIBUS-DP/Modbus RTU（标配），可选EtherCAT或以太网
电源需求24V DC（±10%），功耗≤5W
ABB型号：GBU72 3BHE055094R0002型号：3BHE055094R0002 GBU72型号：GBU72型号：3BHE055094R0002型号：3BHE031197R0001型号：3BHB030310R0001型号：73BHE055094R0002 GBU72型号：73BHE055094R0002型号：GBU72型号：ABB PCS6000 PRODUCT FAMLIY
1.Product Overview
ABB AO820 is a high-performance analog output module launched by ABB,which is the core component of its automated control systems(such as ABB 800xA,AC500 series or industrial IT solutions).This module is designed to convert the digital signals generated by the control system into analog signals(such as voltage and current)required by the industrial site to drive actuators(such as valves,inverters,regulators,etc.),and is widely used in process control,energy management,intelligent manufacturing and environmental monitoring.
2.Core features
Multi-channel high-precision output
Number of channels:Usually 8 independent analog output channels are supported(some models may be extended to 16 channels).
Output type:Can be configured as a voltage(such as±10V,0-10V)or current(such as 0-20mA,4-20mA)signal to meet the needs of different actuators.
Resolution:16-bit(some models support 24-bit),ensuring smoothness and accuracy of the output signal.
Accuracy:±0.1%FS(full scale),suitable for high-precision control scenarios.
Industrial-grade reliability design
Operating temperature range:-20℃to+70℃(extended models support-40℃to+85℃),adapting to extreme environments.
Protection level:IP20(installed in the cabinet),optional IP65 protective shell for outdoor or harsh scenarios.
Isolation protection:The isolation voltage between channels and channels and buses is up to 1500V AC to prevent signal interference and equipment damage.
Anti-interference capability:Built-in electromagnetic compatibility(EMC)filter,complies with IEC 61000-4 standard,effectively suppressing industrial noise.
Flexible communication and integration
Communication protocol:Supports PROFIBUS-DP,Modbus RTU/TCP,EtherCAT or ABB dedicated protocols(such as ABB Totalflow),and is seamlessly compatible with mainstream PLC/DCS systems.
Bus interface:Use standardized interfaces(such as RJ45 or D-sub)to simplify wiring and maintenance.
Hot-swap function:supports live plug-in and unplug to reduce system downtime.
Intelligent diagnosis and maintenance
Real-time monitoring:Independent status detection of each channel(such as disconnection,short circuit,overload),and alarms through LED indicators or control system.
Online calibration:Supports software remote calibration without manual potentiometer adjustment.
Self-diagnosis function:The module has built-in fault detection logic,which can record the last 100 event logs for easy fault tracing.
3.Technical parameters
Parameter category details
Model AO820
8 channels(scalable to 16 channels)
Output type voltage:±10V,0-10V;current:0-20mA,4-20mA(can be configured software)
16-bit resolution(optional 24-bit)
Accuracy±0.1%FS(typical)
Load capacity voltage output:≥1kΩ;current output:≤500Ω
Update rate≤10ms/channel(simultaneous update of all channels)
Communication interface PROFIBUS-DP/Modbus RTU(standard),optional EtherCAT or Ethernet
Power supply requires 24V DC(±10%),power consumption≤5W
