描述
ABB BVC1HRD010502P是ABB Bivector 500系列中的一款伺服驱动器，以下是其产品详情：
基本信息
品牌：ABB
型号：BVC1HRD010502P
产品类型：伺服驱动器
所属系列：Bivector 500系列
技术参数
机座号：9
功率范围：属于大功率版本，具体功率值未明确提及，但该系列驱动器功率范围覆盖0.75 kW至17 kW。
连续输出电流：该系列连续输出电流范围为3.5 A–25 A，BVC1HRD010502P作为机座9的大功率版本，电流输出能力应在较高水平。
通讯接口：标配EtherNet/IP、Modbus-TCP及PROFINET接口，支持即插即用；可选CANopen、DeviceNet接口。
制动电阻：内置制动IGBT，可选75Ω–38Ω制动电阻，连续制动功率120 W–2000 W，峰值制动功率7 kW–16.5 kW。
功能特点
紧凑一体化设计：将整流、逆变、制动单元和I/O接口集成在同一壳体内，机座S尺寸无需外部输入滤波器即可符合EMC指令，节省柜内空间。
安全集成：具备Safe Torque Off（STO）、Safe Brake Control（SBC）等SIL2/PL d级安全功能，无需外部安全继电器即可实现EN 61800-5-2要求。
简易调试：可通过Key-B型手持键盘或ABB PC工具DriveStudio进行参数向导、示波器与自整定，调试时间可缩短50%。
The ABB BVC1HRD010502P is a servo drive in the ABB Bivector 500 series.Below are its product details:
Basic Information
Brand:ABB
Model:BVC1HRD010502P
Product Type:Servo Drive
Series:Bivector 500 Series
Technical Parameters
Frame Size:9
Power Range:This is a high-power version.While the specific power value is not specified,this series covers a power range of 0.75 kW to 17 kW.
Continuous Output Current:This series offers a continuous output current range of 3.5 A–25 A.As a high-power version in frame size 9,the BVC1HRD010502P should have a relatively high current output capability.
Communication Interfaces:EtherNet/IP,Modbus-TCP,and PROFINET interfaces are standard,supporting plug-and-play.CANopen and DeviceNet interfaces are optional.
Braking Resistor:Built-in braking IGBT,optional 75Ω–38Ωbraking resistors.Continuous braking power ranges from 120 W to 2000 W,and peak braking power ranges from 7 kW to 16.5 kW.
Features
Compact Integrated Design:The rectifier,inverter,braking unit,and I/O interface are integrated into a single housing.The S-frame size eliminates the need for an external input filter and complies with EMC directives,saving cabinet space.
Safety Integrated:Features SIL2/PL d safety functions such as Safe Torque Off(STO)and Safe Brake Control(SBC),meeting EN 61800-5-2 requirements without the need for external safety relays.
Easy Commissioning:Parameter wizards,oscilloscopes,and auto-tuning are available via the Key-B handheld keyboard or ABB’s PC tool,DriveStudio,reducing commissioning time by 50%.
