描述
ABB CI615 3BHT300024R1是一款总线耦合器，主要用于工业自动化控制系统中实现I/O扩展功能。以下是其产品详情：
基本信息
产品编号：3BHT300024R1
ABB型号名称：CI615
产品类型：总线耦合器
产地：瑞典
尺寸：约260mm×122mm×25mm
重量：约0.17kg
功能特点
扩展I/O功能：可将远程I/O单元连接到Advant OCS或AC 160 PLC等控制系统，最多可连接两个距离控制器较远的S600 I/O单元，距离可达500米，减少了额外布线的需求，简化了系统设计。
多种协议支持：支持Modbus、DeviceNet、CANopen等多种通信协议，能与多种自动化设备和系统互操作，兼容性强。
快速数据传输：使用IOB_A总线协议进行数据通信，数据传输速率可达1.5Mbps，确保了高效的信号传输。
易于配置和监控：模块上的DIP开关可快速配置I/O单元地址，LED指示灯可清晰显示电源、通信和错误状态，方便用户进行设置和故障排查。
诊断功能：具有诊断功能，可通过配置软件进行故障排除，帮助用户快速定位和解决问题。
技术参数
电源供应：支持12-24VDC电源电压。
功耗：小于1W。
工作温度范围：-20℃至+60℃。
防护等级：IP20。
安装方式：可安装在15mm高的导轨上或用4个螺丝固定。
The ABB CI615 3BHT300024R1 is a bus coupler primarily used in industrial automation control systems to expand I/O functionality.Here are its product details:
Basic Information
Product Number:3BHT300024R1
ABB Model Name:CI615
Product Type:Bus Coupler
Origin:Sweden
Dimensions:Approx.260mm×122mm×25mm
Weight:Approx.0.17kg
Features
Expanded I/O Functionality:Allows connection of remote I/O units to control systems such as Advant OCS or AC 160 PLC.Up to two S600 I/O units located far from the controller can be connected,with a distance of up to 500 meters,reducing the need for additional wiring and simplifying system design.
Multiple Protocol Support:Supports multiple communication protocols such as Modbus,DeviceNet,and CANopen,ensuring interoperability with various automation equipment and systems and strong compatibility.
High-speed data transmission:Utilizes the IOB_A bus protocol for data communication,achieving data transmission rates up to 1.5Mbps,ensuring efficient signal transmission.
Easy configuration and monitoring:DIP switches on the module allow for quick configuration of I/O unit addresses,and LED indicators clearly display power,communication,and error statuses,facilitating user setup and troubleshooting.
Diagnostic functions:Equipped with diagnostic capabilities,allowing for troubleshooting via configuration software,helping users quickly locate and resolve problems.
Technical parameters:
Power supply:Supports 12-24VDC power supply voltage.
Power consumption:Less than 1W.
Operating temperature range:-20℃to+60℃.
Protection rating:IP20.
Mounting method:Can be mounted on a 15mm high DIN rail or secured with 4 screws.
