描述
基本信息
品牌：ABB
类型：整流单元电源板
适用型号：ABB变频整流逆变器ACS800-304/704
电气参数
输入电压：24VAC/DC，50/60Hz
输出负载：15A，250VAC
物理特性
尺寸：77mmx22.5mmx114mm
防护等级：IP20
工作环境
工作温度：-20°C到+55°C
存储温度：-40°C到+70°C
功能特点
通信支持：支持逻辑独立双Profibus DP总线。
电源保护：具有双电源冗余和隔离保护功能。
保护功能：具备过热保护和短路保护功能，可有效保护输出设备。
Basic Information
Brand:ABB
Type:Rectifier Unit Power Board
Applicable Models:ABB ACS800-304/704 Variable Frequency Rectifier Inverter
Electrical Parameters
Input Voltage:24VAC/DC,50/60Hz
Output Load:15A,250VAC
Physical Characteristics
Dimensions:77mm x 22.5mm x 114mm
Protection Rating:IP20
Operating Environment
Operating Temperature:-20°C to+55°C
Storage Temperature:-40°C to+70°C
Features
Communication Support:Supports logically independent dual Profibus DP buses.
Power Protection:Provides dual power supply redundancy and isolation protection.
Protection Functions:Equipped with overheating and short-circuit protection to effectively protect output devices.
