描述
ABB COPA-XE-DE23是电磁流量计相关产品，属于FXE4000系列，是传感器和信号转换器设计成一体的流量测量系统。具体详情如下：
测量介质：可用于精确测量电导率大于5μS/cm的液体、纸浆、泥浆、矿浆的流量。
通信协议：支持Profibus、FF、HART协议、RS-485、ASCII协议、Modbus等多种通信协议。
结构设计：采用一体化设计，具有紧凑的外形，节省安装空间，便于现场安装和维护。
过程连接：提供多种过程连接方式，包括符合DIN11851的卫生型接头，以及符合DIN11864、DIN32676/ISO2852、DIN2999/ISO228等标准的连接，也可根据用户要求提供ABB公司原装的特殊标准连接。
压力与口径：有多种压力和口径规格可选。例如，口径范围可涵盖DN20-DN65等，公称压力根据不同口径有4.0MPa、1.6MPa等不同级别。
安装方式：流量计可以安装在垂直、水平或倾斜管道上。对于口径大于等于DN125的橡胶衬里的传感器，衬里中装有导电橡胶，可确保流体接地。在大口径管道上，传感器可通过标准收缩管方便地安装。
The ABB COPA-XE-DE23 is an electromagnetic flowmeter product from the FXE4000 series.It integrates a sensor and signal converter into a flow measurement system.Specific details are as follows:
Measured Media:Can be used to accurately measure the flow of liquids with conductivity greater than 5μS/cm,pulp,mud,and slurry.
Communication Protocols:Supports multiple communication protocols,including Profibus,FF,HART,RS-485,ASCII,and Modbus.
Structural Design:The integrated design features a compact form factor,saving installation space and facilitating on-site installation and maintenance.
Process Connections:A variety of process connection options are available,including hygienic fittings compliant with DIN11851,as well as connections compliant with DIN11864,DIN32676/ISO2852,DIN2999/ISO228,and other standards.ABB-branded special standard connections are also available upon request.
Pressure and Diameter:Available in a variety of pressure and diameter specifications.For example,the diameter range covers DN20-DN65,with nominal pressures varying from 4.0 MPa to 1.6 MPa depending on the diameter.
Installation:The flowmeter can be installed on vertical,horizontal,or inclined pipes.For rubber-lined sensors with diameters DN125 and above,the lining contains conductive rubber to ensure fluid grounding.For larger diameter pipes,the sensor can be conveniently installed using standard shrink tubing.
