一、产品概述
型号定位：
CP410M是CP400系列中的中高端型号，主打高分辨率显示、多协议通信支持，适用于对操作体验、数据可视化要求较高的场景（如复杂生产线监控、能源调度中心）。
与同系列其他型号（如CP405、CP420）相比，CP410M在屏幕尺寸、通信接口、存储容量上有所升级，同时保持紧凑设计，便于集成到控制柜或操作台。
核心价值：
提升操作效率：通过10.1英寸高分辨率触摸屏和直观界面设计，减少操作员误操作，缩短响应时间。
降低集成成本：支持多种工业协议（如Modbus TCP、Profinet、OPC UA），可直接连接PLC、变频器、传感器等设备，无需额外网关。
增强系统可靠性：采用工业级硬件设计（宽温、抗干扰、冗余电源），确保7×24小时稳定运行。
二、核心功能与特性
1.高性能显示与交互
屏幕参数：
尺寸：10.1英寸TFT LCD显示屏，支持横屏/竖屏安装，适应不同操作场景。
分辨率：1280×800像素（WXGA），显示清晰细腻，可同时展示多组数据、趋势图、报警信息。
亮度：500 cd/m²（典型值），支持自动调光，适应强光或暗光环境。
触摸屏****：电容式多点触控（支持5点触控），响应时间<10ms，支持手势操作（缩放、滑动），提升操作便捷性。
界面设计：
预装软件：基于ABB Automation Builder或CodeSys开发的HMI工程软件，支持图形化组态，可快速创建动态画面、按钮、仪表盘。
多语言支持：内置20+种语言库（包括中文、英文、德文等），方便国际化项目部署。
自定义主题：支持品牌色、字体、图标自定义，匹配企业VI规范。
2.多协议工业通信支持
内置通信接口：
以太网端口：2×10/100/1000Mbps RJ45端口，支持并行冗余协议（PRP）和高速冗余协议（HSR），实现零切换时间（<10μs）的网络冗余。
串口：1×RS485/RS232端口（可选），支持Modbus RTU、Profibus DP等协议，兼容legacy设备。
USB接口：2×USB 2.0端口（Type A），用于固件升级、数据导出、外设连接（如键盘、鼠标、U盘）。
协议兼容性：
PLC协议：支持ABB AC500、AC800M、AC800F系列PLC，以及西门子S7-1200/1500、罗克韦尔ControlLogix、三菱FX/Q系列等第三方PLC（通过OPC UA或Modbus TCP）。
工业以太网协议：Modbus TCP（主/从站）、Profinet IO（控制器/设备）、EtherNet/IP（Scanner/Adapter）、OPC UA Server/Client。
数据采集协议：支持DNP3、IEC 60870-5-104等电力、水务行业专用协议，可直接连接智能电表、RTU设备。
3.工业级硬件设计
环境适应性：
工作温度：-20℃至+60℃（标准型号），可选-40℃至+70℃的宽温版本，适应户外或极端环境。
防护等级：IP65（前面板），防尘防水，可抵御水溅、油污、灰尘。
抗干扰能力：符合IEC 61000-4-6（传导抗扰度）和IEC 61000-4-3（辐射抗扰度）标准，适用于电磁干扰强烈的场合（如变频器柜、电焊车间）。
机械结构：
安装方式：支持面板安装、支架安装、VESA安装，灵活适配不同控制柜或操作台。
材质：外壳采用铝合金+工程塑料，轻量化且坚固，通过IK08冲击测试（可承受5J冲击能量）。
电源与冗余：
工作电压：24V DC（-15%/+20%），支持宽电压输入，适应不同电源质量的场景。
冗余电源：可选双电源输入模块，当主电源故障时，自动切换至备用电源，确保HMI不间断运行。
4.数据安全与远程管理
网络安全防护：
防火墙：内置状态检测防火墙，支持IP/端口过滤、MAC地址绑定，阻止未授权访问。
数据加密：支持TLS 1.2/1.3加密通信，确保OPC UA、Modbus TCP等协议的数据传输安全。
用户认证：支持多级用户权限管理（管理员、操作员、访客），结合审计日志记录所有操作行为。
远程访问：
VNC Server：内置VNC服务器，允许远程桌面访问，方便工程师远程调试、故障排查。
Web服务器：提供HTTP/HTTPS接口，可通过浏览器查看HMI状态、修改参数，无需安装专用软件。
5.扩展性与定制化
存储扩展：
内置存储：256MB Flash+512MB RAM，可存储工程文件、历史数据、报警记录。
外部存储：支持SD卡（最大32GB）或USB存储设备，用于数据备份、日志导出。
定制化服务：
品牌定制：可定制开机画面、LOGO、系统皮肤，匹配企业品牌形象。
功能开发：支持C/C++脚本编程，可实现复杂逻辑控制、算法计算（如PID调节、数据滤波）。
三、技术规格
参数详情
屏幕尺寸10.1英寸TFT LCD
分辨率1280×800像素（WXGA）
触摸屏类型电容式多点触控（5点）
亮度500 cd/m²（典型值）
通信接口2×10/100/1000Mbps RJ45
1×RS485/RS232（可选）
2×USB 2.0
支持协议Modbus TCP/RTU、Profinet IO、EtherNet/IP、OPC UA、DNP3、IEC 60870-5-104
工作电压24V DC（-15%/+20%）
功耗典型值15W
防护等级IP65（前面板）
工作温度-20℃至+60℃（标准），可选-40℃至+70℃
尺寸（W×H×D）约270mm×210mm×50mm（具体以实物为准）
重量约1.2kg
认证CE、UL 508A、cULus、RoHS、IEC 62443-3-3
1.Product Overview
Model positioning:
CP410M is a mid-to-high-end model in the CP400 series.It focuses on high-resolution display and multi-protocol communication support.It is suitable for scenarios with high requirements for operational experience and data visualization(such as complex production line monitoring and energy dispatching center).
Compared with other models in the same series(such as CP405 and CP420),the CP410M has been upgraded in screen size,communication interface,and storage capacity,while maintaining a compact design for easy integration into the control cabinet or operating table.
Core Values:
Improve operational efficiency:Reduce operator misoperation and shorten response time with a 10.1-inch high-resolution touch screen and intuitive interface design.
Reduce integration costs:Supports multiple industrial protocols(such as Modbus TCP,Profinet,OPC UA),which can directly connect to PLC,frequency converter,sensor and other devices without additional gateways.
Enhanced system reliability:adopts industrial-grade hardware design(wide temperature,anti-interference,redundant power supply)to ensure stable operation in 7×24 hours.
2.Core functions and characteristics
1.High-performance display and interaction
Screen parameters:
Size:10.1-inch TFT LCD display,supports horizontal screen/vertical screen installation,adapting to different operating scenarios.
Resolution:1280×800 pixels(WXGA),the display is clear and delicate,and can display multiple sets of data,trend charts,and alarm information at the same time.
Brightness:500 cd/m²(typical),supports automatic dimming,adapting to strong or dark light environments.
Touch screen****:Capacitive multi-touch(supports 5-touch),response time<10ms,support gesture operation(zoom,slide),improve operation convenience.
Interface design:
Preinstalled software:HMI engineering software developed based on ABB Automation Builder or CodeSys,supports graphical configuration and can quickly create dynamic pictures,buttons,and dashboards.
Multilingual support:Built-in 20+language libraries(including Chinese,English,German,etc.)to facilitate international project deployment.
Custom theme:Support brand colors,fonts,icons to customize,match corporate VI specifications.
2.Multi-protocol industrial communication support
Built-in communication interface:
Ethernet port:2×10/100/1000Mbps RJ45 port,supports parallel redundancy protocol(PRP)and high-speed redundancy protocol(HSR),achieving network redundancy with zero switching time(<10μs).
Serial port:1×RS485/RS232 port(optional),supports Modbus RTU,Profibus DP and other protocols,and is compatible with legacy devices.
USB interface:2×USB 2.0 port(Type A),used for firmware upgrade,data export,peripheral connection(such as keyboard,mouse,USB disk).
Protocol Compatibility:
PLC protocol:supports ABB AC500,AC800M,AC800F series PLCs,as well as third-party PLCs such as Siemens S7-1200/1500,Rockwell ControlLogix,Mitsubishi FX/Q series,etc.(through OPC UA or Modbus TCP).
Industrial Ethernet protocols:Modbus TCP(master/slave),Profinet IO(controller/device),EtherNet/IP(Scanner/Adapter),OPC UA Server/Client.
Data acquisition protocol:supports DNP3,IEC 60870-5-104 and other special protocols for the power and water industries,and can directly connect smart meter and RTU equipment.
3.Industrial hardware design
Environmental adaptability:
Operating temperature:-20℃to+60℃(standard model),wide temperature versions from-40℃to+70℃are available for outdoor or extreme environments.
Protection level:IP65(front panel),dust-proof and water-proof,can resist water splashes,oil stains,and dust.
Anti-interference ability:complies with IEC 61000-4-6(conductive immunity)and IEC 61000-4-3(radiation immunity)standards,and is suitable for occasions where electromagnetic interference is strong(such as inverter cabinets,welding workshops).
Mechanical structure:
Installation method:Support panel installation,bracket installation,VESA installation,and flexibly adapt to different control cabinets or operating tables.
Material:The shell is made of aluminum alloy+engineering plastic,lightweight and sturdy,passing the IK08 impact test(can withstand 5J impact energy).
Power supply and redundancy:
Operating voltage:24V DC(-15%/+20%),supports wide voltage input,adapting to scenarios with different power quality.
Redundant power supply:Optional Dual power input module,automatically switch to the backup power supply when the main power supply fails to ensure uninterrupted operation of the HMI.
4.Data security and remote management
Network security protection:
Firewall:Built-in status detection firewall,supports IP/port filtering,MAC address binding,and prevents unauthorized access.
Data encryption:Supports TLS 1.2/1.3 encrypted communication to ensure the security of data transmission of protocols such as OPC UA,Modbus TCP.
User authentication:supports multi-level user permission management(administrator,operator,visitor),and records all operational behaviors in combination with audit logs.
Remote access:
VNC Server:Built-in VNC server,allowing remote desktop access,convenient for engineers to remote debugging and troubleshoot.
Web server:Provides an HTTP/HTTPS interface,which can view the HMI status and modify parameters through the browser,without installing special software.
5.Scalability and customization
Storage extension:
Built-in storage:256MB Flash+512MB RAM,which can store project files,historical data,and alarm records.
External storage:Supports SD card(maximum 32GB)or USB storage devices for data backup and log export.
Customized services:
Brand customization:customizable boot screen,LOGO,system skin,matching the corporate brand image.
Functional development:supports C/C++script programming,which can realize complex logic control,algorithm calculation(such as PID adjustment,data filtering).
3.Technical specifications
Parameters Details
Screen size 10.1 inch TFT LCD
Resolution 1280×800 pixels(WXGA)
Touch screen type Capacitive multi-touch(5 points)
Brightness 500 cd/m²(typical)
Communication interface 2×10/100/1000Mbps RJ45
1×RS485/RS232(optional)
2×USB 2.0
Support protocols Modbus TCP/RTU,Profinet IO,EtherNet/IP,OPC UA,DNP3,IEC 60870-5-104
Operating voltage 24V DC(-15%/+20%)
Power consumption Typical value 15W
Protection level IP65(front panel)
Operating temperature-20℃to+60℃(standard),optional-40℃to+70℃
Size(W×H×D)About 270mm×210mm×50mm(the specific object shall prevail)
Weight approximately 1.2kg
Certification CE,UL 508A,cULus,RoHS,IEC 62443-3-3
