描述
ABB CP420 B 1SBP260182R1001是一款工业控制触摸屏，属于ABB CP400系列。以下是其产品详情：
基本信息
品牌：ABB
型号：CP420 B
产品编号：1SBP260182R1001
类型：控制面板
产地：中国台湾
尺寸：屏幕可视区域为111mm×61mm
重量：约0.47kg
技术参数
电源供应：20.4-27.6V DC
功耗：12VA
工作温度：0-50℃
存储温度：-10-60℃
通信接口：RS-232/RS-485（串口1），RS-422/RS-485（串口2）
通信速度：4.8-187.5kbd
屏幕规格：4.7英寸STN触摸屏，16:9宽屏，分辨率240×128像素，16级蓝色背光
内存：4MB ROM，用户程序存储容量4000KB
防护等级：前面板IP65
功能特点
显示直观：4.7英寸触摸屏提供清晰直观的显示界面，16级蓝色背光确保在不同光照条件下都能清晰可见。
通信灵活：具备RS-232/RS-485、RS-422/RS-485串口，支持多种通信方式，可与其他设备进行数据传输和通信。
安全保护：具有密码保护功能，有9个用户级别，可有效防止非授权访问和操作。
功能丰富：支持报警管理、趋势显示、宏功能和梯形图子屏幕等软件功能，方便用户对系统进行监控和管理。
安装方便：可前面板安装，安装位置为0-135°。
ABB CP420 B 1SBP260182R1001 is an industrial control touch screen,belonging to the ABB CP400 series.The following are product details:
Basic Information
Brand:ABB
Model:CP420 B
Product Number:1SBP260182R1001
Type:Control Panel
Origin:Taiwan,China
Dimensions:Viewable screen area:111mm x 61mm
Weight:Approximately 0.47kg
Technical Parameters
Power Supply:20.4-27.6V DC
Power Consumption:12VA
Operating Temperature:0-50°C
Storage Temperature:-10-60°C
Communication Interface:RS-232/RS-485(Serial Port 1),RS-422/RS-485(Serial Port 2)
Communication Speed:4.8-187.5kbd
Display Specifications:4.7-inch STN touch screen,16:9 widescreen,240 x 128 pixel resolution,16-level blue backlight
Memory:4MB ROM,user program storage capacity:4000KB
Protection Level:Front Panel IP65
Features
Intuitive Display:The 4.7-inch touch screen provides a clear and intuitive interface,and the 16-level blue backlight ensures clear visibility in all lighting conditions.
Flexible Communication:RS-232/RS-485 and RS-422/RS-485 serial ports support multiple communication methods for data transmission and communication with other devices.
Security:Password protection with 9 user levels effectively prevents unauthorized access and operation.
Feature-Rich:Supports software features such as alarm management,trend display,macros,and ladder diagram subscreens,making it easy for users to monitor and manage the system.
Easy Installation:Front panel mountable,with mounting positions ranging from 0 to 135 degrees.
